DAHUA Unveils Next-Gen DAHUA Network Camera Technology

IPC-HDW3549H-AS-PV

* The parameters and datasheets below can only be applied to 3549-PV-S4 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One press arming/disarming through alarm input.

DAHUA IPC-HDW5442TM-ASE 4MP IR Fixed-focal Eyeball WizMind Network Camera

DAHUA IPC-HDW2841T-ZS 8MP IR Vari-focal Eyeball WizSense Network Camera



IPC-HDW2841T-ZS



> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@20 fps and supports 2688 × 1520 (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD Plus.



DAHUA IPC-HFW4831T-ASE 8MP WDR IR Mini Bullet Network Camera



IPC-HFW4831T-ASE



8MP WDR IR Mini Bullet Network Camera

> 1/2.5” 8Megapixel progressive scan STARVISTM CMOS
> H. 265&H.264 triple-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Smart Detection supported
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.8mm fixed lens (4mm optional)
> Max. IR LEDs Length 80m
> Micro SD Memory,IP67, IK10, PoE



DAHUA IPC-HDBW3441R-ZS-S2 4MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW3441R-ZS-S2



> Outputs max. 4 MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HUM8441-E1 4MP Covert Pinhole WizMind Network Camera-Main Box



IPC-HUM8441-E1



> Starlight 4MP 1/2.7″ CMOS image sensor, excellent low luminance performance and high definition of images.

> Outputs max. 4MP (2688 × 1520)@25/30 fps.

> H.265 codec allows high compression ratio and ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.

> 12V DC/PoE power supply facilitates installation.

> Multiple lens unit optional; require a lens unit to work together



DAHUA IPC-HDW2831TM-AS-S2 8MP Lite IR Fixed-focal Eyeball Network Camera



IPC-HDW2831TM-AS-S2



> 8MP, 1/2.7″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (3840 × 2160) @15 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max IR distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Supports max. 256 GB Micro SD card, built-in MIC

> 12V DC/PoE power supply

> IP67 protection



DAHUA IPC-HFW3441T-ZS-S2 4MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW3441T-ZS-S2



> Outputs max. 4 MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports ); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HFW2841T-ZAS 8MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW2841T-ZAS



> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 (optional) protection.

> SMD Plus.



DAHUA IPC-HDBW2841R-ZAS 8MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW2841R-ZAS



> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 protection.

> SMD Plus.



DAHUA IPC-HDBW5442R-ASE 4MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5442R-ASE



* The parameters and datasheets below can only be applied to 5442-ASE-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HFW4831E-SE 8MP WDR IR Mini Bullet Network Camera



IPC-HFW4831E-SE



8MP WDR IR Mini Bullet Network Camera

> 1/2.5” 8Megapixel progressive scan STARVIS™ CMOS
> H. 265&H.264 triple-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Smart Detection supported
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.8mm fixed lens (4mm optional)
> Max. IR LEDs Length 40m
> Micro SD Memory,IP67, PoE



DAHUA IPC-HDW3541T-ZS-S2 5MP IR Vari-focal Eyeball WizSense Network Camera



IPC-HDW3541T-ZS-S2



> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HFW3449T1-AS-PV 4MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera



IPC-HFW3449T1-AS-PV



* The parameters and datasheets below can only be applied to 3449-PV-S4 series.

> 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



DAHUA IPC-HFW5442T-SE 4MP IR Fixed-focal Bullet WizMind Network Camera



IPC-HFW5442T-SE



* The parameters and datasheets below can only be applied to 5442-SE-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HFW3541T-ZS-S2 5MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW3541T-ZS-S2



> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HDBW3441R-ZAS-S2 4MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW3441R-ZAS-S2



> Outputs max. 4 MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HFW3441T-ZAS-S2 4MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW3441T-ZAS-S2



> Outputs max. 4 MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports ); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HDBW2841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW2841R-ZS



> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 protection.

> SMD Plus.



DAHUA IPC-HDW5241T-ZE 2MP IR Vari-focal Eyeball WizMind Network Camera



IPC-HDW5241T-ZE



* The parameters and datasheets below can only be applied to 5241-Z-S3 series.

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.



DAHUA IPC-HDW3849H-AS-PV 8 MP Smart Dual Illumination Active Deterrence Fixed-focal Eyeball WizSense Network Camera



IPC-HDW3849H-AS-PV



* The parameters and datasheets below can only be applied to 3849-PV-S4 series.

> 8-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One press arming/disarming through alarm input.



DAHUA SD22204UE-GN-W 2MP 4x Starlight PTZ Wi-Fi Network Camera



SD22204UE-GN-W



2MP 4x Starlight PTZ Wi-Fi Network Camera

> 1/2.8” STARVIS™ CMOS
> Powerful 4x optical zoom
> Support Starlight
> WDR, Day/Night(ICR), Ultra DNR
> Max. 25/30fps@1080P· Max 100°/s pan speed
> Support Wi-Fi
> IP66, IK10



DAHUA IPC-HDBW3541R-ZS-S2 5MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW3541R-ZS-S2



> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HDBW2531R-ZAS-S2 5MP Lite IR Vari-focal Dome Network Camera



IPC-HDBW2531R-ZAS-S2



5MP Lite IR Vari-focal Dome Network Camera

> 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 5MP (2592 × 1944) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max IR distance: 40 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 GB Micro SD card

> 12V DC/PoE power supply

> IP67, IK10 protection grade



DAHUA IPC-HDW3549H-ZAS-PV 5 MP Smart Dual Light Active Deterrence Vari-focal Eyeball WizSense Network Camera



IPC-HDW3549H-ZAS-PV



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual Mic; built-in speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-tap arming/disarming through alarm input



DAHUA IPC-HFW3549T1-AS-PV 5MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera



IPC-HFW3549T1-AS-PV



* The parameters and datasheets below can only be applied to 3549-PV-S4 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



DAHUA IPC-HFW3541T-ZAS-S2 5MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW3541T-ZAS-S2



> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HUM8241-E2 2MP Covert Pinhole WizMind Network Camera-Main Box



IPC-HUM8241-E2



> Starlight 2MP 1/2.8″ CMOS image sensor, excellent low luminance performance and high definition of images.

> Outputs max. 2 channels 2MP (1920 × 1080)@25/30 fps.

> H.265 codec allows high compression ratio and ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.

> 12V DC/PoE power supply facilitates installation.

> Multiple lens unit optional; require a lens unit to work together



DAHUA IPC-HFW5442T-ASE 4MP IR Fixed-focal Bullet WizMind Network Camera



IPC-HFW5442T-ASE



* The parameters and datasheets below can only be applied to 5442-ASE-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW5449R-ASE-LED 4MP Full-color Fixed-focal Warm LED Dome WizMind Network Camera



IPC-HDBW5449R-ASE-LED



> 4MP 1/1.8″ CMOS image sensor, low illuminance, high image definition .

> Outputs max. 4MP (2688 × 1520) @30 fps.

> Built-in warm illuminator, and the max. illumination distance is 30 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; Supports max. 256 G Micro SD card, built-in Mic.

> 12V DC/PoE power supply.

> ePoE, IP67, IK10 protection.

> SMD 3.0



DAHUA IPC-HFW5449T-ASE-LED 4MP Full-color Fixed-focal Warm LED Bullet WizMind Network Camera



IPC-HFW5449T-ASE-LED



> 4MP 1/1.8″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 4MP (2688 × 1520) @30 fps.

> Built-in warm illuminator, and the max. illumination distance is 60 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, Built-in Mic.

> 12V DC/PoE power supply.

> ePoE , IP67 protection.

> SMD 3.0.



DAHUA IPC-HDBW3541R-ZAS-S2 5MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW3541R-ZAS-S2



> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HFW5241E-ZE 2MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5241E-ZE



* The parameters and datasheets below can only be applied to 5241-Z-S3 series.

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW5241E-ZE 2MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5241E-ZE



* The parameters and datasheets below can only be applied to 5241-Z-S3 series.

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW4831E-ASE 8MP IR Mini Dome Network Camera



IPC-HDBW4831E-ASE



8MP IR Mini Dome Network Camera

> 1/2.5” 8Megapixel progressive scan STARVISTM CMOS
> H.265&H.264 triple-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Smart Detection supported
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.8mm fixed lens (4mm optional)
> 1/1 Alarm in/out, 1/1 audio in/out
> Max. IR LEDs Length 30m
> Micro SD memory, IP67, IK10, PoE



DAHUA IPC-HDBW5831R-ZE 8MP WDR IR Dome Network Camera



IPC-HDBW5831R-ZE



8MP WDR IR Dome Network Camera

> 1/2.5” 8Megapixel progressive scan STARVIS™ CMOS
> H.265&H.264 dual-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~12mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD card memory, IP67,IK10, PoE





DAHUA IPC-HFW2541T-ZAS 5MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW2541T-ZAS



> Outputs max. 5 MP (2592 × 1944) @20 fps, and supports 4 MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion and tripwire (the two functions support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection (Only – ZAS supports) , no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports).
> supports max. 256 G Micro SD card.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD Plus.



DAHUA IPC-HFW3849T1-AS-PV 8MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera



IPC-HFW3849T1-AS-PV



* The parameters and datasheets below can only be applied to 3849-PV-S4 series.

> 8-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



DAHUA IPC-HDW3449H-ZAS-PV 4 MP Smart Dual Light Active Deterrence Vari-focal Eyeball WizSense Network Camera



IPC-HDW3449H-ZAS-PV



> 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual Mic; built-in speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-tap arming/disarming through alarm input.



DAHUA PTZ1C203UE-GN 2MP 3x Starlight IR PTZ Network Camera



PTZ1C203UE-GN



2MP 3x Starlight IR PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 3x optical zoom
> Starlight technology
> Max. 25/30fps@1080P
> IVS
> WDR
> H.265 Encoding
> Support PoE
> IR distance up to 20m
> IP66





DAHUA PTZ1C203UE-GN-W 2MP 3X Starlight IR PTZ Wi-Fi Network Camera



PTZ1C203UE-GN-W



2MP 3X Starlight IR PTZ Wi-Fi Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 3x optical zoom
> Starlight technology
> Max. 25/30fps@1080P
> IVS
> WDR
> H.265 Encoding
> Support Wi-Fi
> IR distance up to 20m
> IP66





DAHUA SD29204UE-GN 2MP 4x Starlight IR PTZ Network Camera



SD29204UE-GN







DAHUA IPC-HFW5842T-SE 8MP IR Fixed-focal Bullet WizMind Network Camera



IPC-HFW5842T-SE



* The parameters and datasheets below can only be applied to 5842-ASE-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA SD22404T-GN 4MP 4x PTZ Network Camera



SD22404T-GN



4MP 4x PTZ Network Camera

> 1/3” 4Megapixel CMOS
> Powerful 4x optical zoom
> WDR, Day/Night(ICR), Ultra DNR
> Max. 25/30fps@4M/3M
> IVS
> Support PoE
> IP66, IK10



DAHUA IPC-HFW5842T-ASE 8MP IR Fixed-focal Bullet WizMind Network Camera



IPC-HFW5842T-ASE



8MP IR Fixed-focal Bullet WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842-ASE-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA SD29204UE-GN-W 2MP 4x Starlight IR PTZ Wi-Fi Network Camera



SD29204UE-GN-W







DAHUA IPC-HDW5449TM-SE-LED 4MP Full-color Fixed-focal Warm LED Eyeball WizMind Network Camera



IPC-HDW5449TM-SE-LED



> 4MP 1/1.8″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 4MP (2688 × 1520) @30 fps.

> Built-in warm illuminator, and the max. illumination distance is 30 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various. bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Supports max. 256 G Micro SD card, Built-in Mic.

> 12V DC/PoE power supply.

> ePoE,IP67 protection.

> SMD 3.0.



DAHUA IPC-HDW4831EM-ASE 8MP IR Eyeball Network Camera



IPC-HDW4831EM-ASE



8MP IR Eyeball Network Camera

> 1/2.5” 8Megapixel progressive scan STARVISTM CMOS
> H.265&H.264 triple-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Smart detection supported
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.8mm fixed lens (4mm optional)
> Built-in Mic
> Max. IR LEDs Length 50m
> Micro SD memory, IP67, PoE



DAHUA IPC-HFW3841T-ZAS-S2 8MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW3841T-ZAS-S2



> Outputs max. 8 MP (3840 × 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Supports the AFSA (Anti-flicker Self-adaption) function, which automatically eliminates flicker
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HDW3849H-ZAS-PV 8 MP Smart Dual Light Active Deterrence Vari-focal Eyeball WizSense Network Camera



IPC-HDW3849H-ZAS-PV



> 8-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual Mic; built-in speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-tap arming/disarming through alarm input.



DAHUA IPC-HDBW5831E-ZE 8MP WDR IR Dome Network Camera



IPC-HDBW5831E-ZE



8MP WDR IR Dome Network Camera

> 1/2.5” 8Megapixel progressive scan STARVIS™ CMOS
> H.265&H.264 dual-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~12mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD card memory, IP67,IK10, PoE+





DAHUA IPC-HFW3841T-ZS-S2 8MP IR Vari-focal Bullet WizSense Network Camera



IPC-HFW3841T-ZS-S2



> Outputs max. 8 MP (3840 × 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Supports the AFSA (Anti-flicker Self-adaption) function, which automatically eliminates flicker
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HFW3449T1-ZAS-PV 4MP Smart Dual Illumination Active Deterrence Vari-focal Bullet WizSense Network Camera



IPC-HFW3449T1-ZAS-PV



> 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



DAHUA SD22404T-GN-W 4MP 4x PTZ Wi-Fi Network Camera



SD22404T-GN-W



4MP 4x PTZ Wi-Fi Network Camera

> 1/3” 4Megapixel CMOS
> Powerful 4x optical zoom
> WDR, Day/Night(ICR), Ultra DNR
> Max. 25/30fps@4M/3M
> IVS
> Support Wi-Fi
> IP66, IK10



DAHUA IPC-HDW3841T-ZS-S2 8MP IR Vari-focal Eyeball WizSense Network Camera



IPC-HDW3841T-ZS-S2



> Outputs max. 8 MP (3840 × 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HF5541F-ZE 5MP Box WizMind Network Camera



IPC-HF5541F-ZE



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-iris, the camera can control the iris more precisely for better image effect.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> SMD 3.0



DAHUA IPC-HDW5541T-ZE 5MP IR Vari-focal Eyeball WizMind Network Camera



IPC-HDW5541T-ZE



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.



DAHUA IPC-HDBW3841R-ZS-S2 8MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW3841R-ZS-S2



> Outputs max. 8MP (3840 × 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HDBW3841R-ZAS-S2 8MP IR Vari-focal Dome WizSense Network Camera



IPC-HDBW3841R-ZAS-S2



> Outputs max. 8MP (3840 × 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); max. 256 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 protection.
> SMD 4.0, AI SSA.



DAHUA IPC-HDBW5831E-Z5E 8MP WDR IR Dome Network Camera



IPC-HDBW5831E-Z5E



8MP WDR IR Dome Network Camera

> 1/2.5” 8Megapixel progressive scan CMOS
> H.265&H.264 dual-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 7mm ~35mm 5X zoom lens
> Max. IR LEDs Length 100m
> Micro SD card memory, IP67,IK10, PoE+







DAHUA IPC-HFW5831E-ZE 8MP WDR IR Bullet Network Camera



IPC-HFW5831E-ZE



8MP WDR IR Bullet Network Camera

> 1/2.5” 8Megapixel progressive scan STARVIS™ CMOS
> H.265&H.264 dual-stream encoding
> 15fps@4K(3840×2160),25/30fps@3Mp(2304×1296)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~12mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory, IP67, IK10, PoE



DAHUA IPC-HFW5442E-ZHE 4MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5442E-ZHE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0

.



DAHUA IPC-HDBW5842R-ASE 8MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5842R-ASE



8MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842-ASE-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA IPC-HDW5842TM-ASE 8MP IR Fixed-focal Eyeball WizMind Network Camera



IPC-HDW5842TM-ASE



8MP IR Fixed-focal Eyeball WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842-ASE-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.





DAHUA IPC-HDBW5541E-ZE 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5541E-ZE



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW3549R1-ZAS-PV 5MP Smart Dual Illumination Active Deterrence Vari-focal Dome WizSense Network Camera



IPC-HDBW3549R1-ZAS-PV



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67, IK10 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



DAHUA IPC-HFW5541E-ZE 5MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5541E-ZE



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA IPC-HDBW5449R1-ZE-LED 4MP Full-color Vari-focal Warm LED Dome WizMind Network Camera



IPC-HDBW5449R1-ZE-LED



> 4MP 1/1.8″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 4MP (2688 × 1520) @30 fps.

> Built-in warm illuminator, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker, support two-way talk.

> 12V DC/PoE power supply.

> ePoE, IP67, IK10 protection.

> SMD 3.0.



DAHUA IPC-HFW5241E-Z5E 2MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5241E-Z5E



* The parameters and datasheets below can only be applied to 5241-Z-S3 series.

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW5241E-Z5E 2MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5241E-Z5E



* The parameters and datasheets below can only be applied to 5241-Z-S3 series.

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HUM8441-E2 4 MP Covert Pinhole WizMind Network Camera-Main Box



IPC-HUM8441-E2



> Starlight 4-MP 1/2.7″ CMOS image sensor, excellent low luminance performance and high definition of images.

> Outputs max. 2 channels 5 MP (2592 × 1944) @20 fps. 4 MP (2688 ×1520)@25/30 fps.

> H.265 codec allows high compression ratio and ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and face detection.

> Object monitoring: abandoned object, missing object.

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.

> 12 VDC/PoE power supply facilitates installation.

> Multiple Lens Unit optional.

> Require a Lens Unit to work together.



DAHUA IPC-HF5442F-ZE 4MP Box WizMind Network Camera



IPC-HF5442F-ZE



* The parameters and datasheets below can only be applied to 5442-Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> 12 VDC power output, and max. current 165 mA, easy for installation.

> SMD 3.0.



DAHUA IPC-HFW5842E-ASE 8MP IR Fixed-focal Bullet WizMind Network Camera



IPC-HFW5842E-ASE



8MP IR Fixed-focal Bullet WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842-ASE-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30fps.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.





DAHUA IPC-HFW5831E-Z5E 8MP WDR IR Bullet Network Camera



IPC-HFW5831E-Z5E



8MP WDR IR Bullet Network Camera

> 1/2.5” 8Megapixel progressive scan CMOS
> H.265&H.264 dual-stream encoding
> 15fps@4K(3840×2160),25/30fps@3Mp(2304×1296)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 7mm ~35mm 5x zoom lens
> 2/1 Alarm in/out, 1/1 audio in/out
> Max. IR LEDs Length 100m
> Micro SD memory, IP67, IK10, PoE



DAHUA IPC-HDW5449H-ASE-D2 4 MP Dual Lens Fixed-focal Eyeball WizMind Full-color Network Camera



IPC-HDW5449H-ASE-D2



> Dual AI sensors with multi-spectral imaging technology that produces colorful images in low illumination conditions.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> Built-in warm light/IR LED, with a maximum illumination distance of 50 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and parking detection.

> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, and face exposure.

> People counting: Queue management, people counting in area, entered/exited people counting, and generating and exporting report (day/month/year).

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in Mic and speaker, support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.



DAHUA IPC-HUM8241-E1-L1 2MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8241-E1-L1



> Outputs max. 2MP (1920 × 1080)@25/30 fps.
> H.265 codec, high compression ratio, and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.
> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HDW5442T-ZE 4MP IR Vari-focal Eyeball WizMind Network Camera



IPC-HDW5442T-ZE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.



DAHUA IPC-PDW5849-A180-E2-ASTE 2¡Á4MP Full-color Duo Splicing WizMind Network Camera



IPC-PDW5849-A180-E2-ASTE



> Outputs 180° wide angle splicing image.

> Outputs max. 8 MP (4096 × 1800)@25 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light, and the max. illumination distance is 40 m.

> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card, built-in Mic and speaker, support two-way talk.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> EPTZ: Enlarge and track the targets of intelligent alarms.

> SMD.



DAHUA IPC-HDW5831R-ZE 8MP WDR IR Eyeball Network Camera



IPC-HDW5831R-ZE



8MP WDR IR Eyeball Network Camera

> 1/2.5” 8Megapixel progressive scan CMOS
> H.265&H.264 dual-stream encoding
> 15fps@4K(3840×2160),25/30fps@3M(2304×1296)
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~12mm motorized lens
> Built-in Mic
> Max. IR LEDs Length 50m
> Micro SD card memory, IP67, PoE





DAHUA IPC-HDBW5541E-ZHE 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5541E-ZHE



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.



DAHUA IPC-HDBW3849R1-ZAS-PV 8MP Smart Dual Illumination Active Deterrence Vari-focal Dome WizSense Network Camera



IPC-HDBW3849R1-ZAS-PV



> 8-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67, IK10 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input



DAHUA IPC-HUM8241E-E1-L3-S2 2MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8241E-E1-L3-S2



> Starlight 2-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2 MP (1920 × 1080)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card

> 12 VDC/PoE power supply, easy for installation.

> The Network Camera Main Box connects to the lens through the included 8 m coaxial cable.

> IP67 protection (L3).

> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HUM8241-E1 2MP Covert Pinhole WizMind Network Camera-Main Box



IPC-HUM8241-E1



> Outputs max. 2MP (1920 × 1080)@25/30 fps.
> H.265 codec allows high compression ratio and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.
> Multiple lens unit optional; require a lens unit to work together.



DAHUA IPC-HUM8241-E1-L4 2MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8241-E1-L4



> Outputs max. 2MP (1920 × 1080)@25/30 fps.
> H.265 codec, high compression ratio, and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.
> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HFW5541E-ZHE 5MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5541E-ZHE



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.



DAHUA IPC-HFW5442E-ZE 4MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5442E-ZE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW5442E-ZE 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5442E-ZE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HUM8241-E1-L5 2MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8241-E1-L5



> Outputs max. 2MP (1920 × 1080)@25/30 fps.
> H.265 codec, high compression ratio, and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.
> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HFW5241E-Z12E 2MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5241E-Z12E



* The parameters and datasheets below can only be applied to 5241-Z-S3 series.

> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2MP (1920×1080) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 150 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HUM8441E-E1-L3-S2 4MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8441E-E1-L3-S2



> Starlight 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> The Network Camera Main Box connects to the lens through the included 8 m coaxial cable.

> IP67 protection (L3).

> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HDW8441X-3D 4MP WizMind Dual-Lens Network Camera



IPC-HDW8441X-3D



> 4-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2560 × 1440) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 20 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> People counting: Queue management, people counting in area, entry/ exit/pass number counting, and it can output daily/monthly/yearly report.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485, BNC, supports max. 512 G Micro SD card; built in MIC and speaker.

> 12 VDC/PoE power supply, 12 VDC power output, and max. current 165 mA, easy for installation.

> IP67and IK10 protection.

> Supports altitude self-adaptive, which adapts the altitude and angle of installation to improve the detection effect of people.

> Supports crowd detection and leave post detection.



DAHUA IPC-HDW8341X-BV-3D 3MP WizMind Dual-Lens Network Camera



IPC-HDW8341X-BV-3D



> 3MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 3MP (2048 × 1536) @30 fps

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Stereo analysis: Fall detection, people approaching detection, people No. error, stay detection, and violence detection

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G

> Micro SD card, built-in Mic and speaker. Siren active deterrence, built-in 8 voices, and user can import custom voices.

> 12V DC/PoE power supply

> IP67, IK10 protection



DAHUA IPC-HFW3549T1-ZAS-PV 5MP Smart Dual Illumination Active Deterrence Vari-focal Bullet WizSense Network Camera



IPC-HFW3549T1-ZAS-PV



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4 MP (2688 × 1520) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



DAHUA IPC-HUM8441-E1-L1 4MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8441-E1-L1



> Outputs max. 4MP (2688 × 1520)@25/30 fps.
> H.265 codec, high compression ratio, and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.
> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA SD49212T-HN 2MP 12x Starlight IR PTZ Network Camera



SD49212T-HN



2MP 12x Starlight IR PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 12x optical zoom
> Starlight technology
> Max.25/30fps@1080P
> IVS
> Support PoE+
> IR distance up to 100m
> IP66



DAHUA SD42212T-HN(-S2) 2MP 12x Starlight PTZ Network Camera



SD42212T-HN(-S2)



2MP 12x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 12x optical zoom
> Support Triple-streams encoding
> Max. 25/30fps@1080P
> IVS
> Support PoE+
> IP66, IK10



DAHUA IPC-HUM8441-E1-L4 4MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8441-E1-L4



> Outputs max. 4MP (2688 × 1520)@25/30 fps.
> H.265 codec, high compression ratio, and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.
> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HDBW5442E-ZHE 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5442E-ZHE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.



DAHUA IPC-HFW5842E-ZE 8MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5842E-ZE



* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA IPC-HDBW5842E-ZE 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5842E-ZE



8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA IPC-HUM8441-E1-L5 4MP Covert Pinhole WizMind Network Camera-KIT



IPC-HUM8441-E1-L5



> Outputs max. 4MP (2688 × 1520)@25/30 fps.
> H.265 codec, high compression ratio, and ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and face detection.
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card space warning, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-232; max. 256 G Micro SD card.
> 12V DC/PoE power supply facilitates installation.

> Power on after connecting the lens to the back-end device; otherwise the device might be damaged.



DAHUA IPC-HDW5842T-ZE 8MP IR Vari-focal Eyeball WizMind Network Camera



IPC-HDW5842T-ZE



* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.

> Supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 protection.

> SMD 3.0.





DAHUA SD40212T-HN(-S2) 2MP 12x Starlight PTZ Network Camera



SD40212T-HN(-S2)



2MP 12x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 12x optical zoom
> Support Triple-streams encoding
> Max. 25/30fps@1080P
> IVS
> Support PoE+
> IP66, IK10



DAHUA SD42C212T-HN(-S2) 2MP 12x Starlight PTZ Network Camera



SD42C212T-HN(-S2)



2MP 12x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 12x optical zoom
> Support Triple-streams encoding
> Max. 25/30fps@1080P
> IVS
> Support PoE+
> IK10



DAHUA IPC-HFW5541E-Z5E 5MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5541E-Z5E



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HDBW5541E-Z5E 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5541E-Z5E



* The parameters and datasheets below can only be applied to 5541-Z-S3 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2960×1668) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 24V AC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HFW5442H-ZHE 4MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5442H-ZHE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.



DAHUA IPC-HDBW5442H-ZHE 4MP IR Vari-focal Dome WizMind Network Camera



IPC-HDBW5442H-ZHE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.



DAHUA IPC-HF5842F-ZE 8MP Box WizMind Network Camera



IPC-HF5842F-ZE



* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> 12 VDC power output, and max. current 165 mA, easy for installation.

> SMD 3.0.





DAHUA IPC-HF7442F-Z-S2 4MP BOX WizMind Network Camera



IPC-HF7442F-Z-S2



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485, BNC, supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/24 VAC/PoE power supply, 12 VDC power output, and max. current 165 mA, easy for installation.



DAHUA PSDW5631S-B360 3x2MP Multi-Sensor Network Camera+PTZ Camera



PSDW5631S-B360



3x2MP Multi-Sensor Network Camera+PTZ Camera

> Panoramic: Three 1/2.7” 2Megapixel progressive scan CMOS
> PTZ: 1/2.7” 2Megapixel progressive scan CMOS
> H.265/H.264 dual-stream encoding

> 25fps@1920×1080

> Support 360-degree no-splicing panoramic view

> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Max IR LEDs Length 15m
> Micro SD card slot, up to 256GB
> PoE+



DAHUA IPC-HFW5449T1-ASE-D2 4 MP Dual Lens Fixed-focal Bullet WizMind Full-color Network Camera



IPC-HFW5449T1-ASE-D2



> Dual AI sensors with multi-spectral imaging technology that produces colorful images in low illumination conditions.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> Built-in warm light/IR LED, with a maximum illumination distance of 50 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, and parking detection.

> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, and face exposure.

> People counting: Queue management, people counting in area, entered/exited people counting, and generating and exporting report (day/month/year).

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in Mic and speaker, support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.



DAHUA IPC-HDBW5442E-Z4E 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5442E-Z4E



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA SD52C225U-HNI 2MP 25x Starlight PTZ Network Camera



SD52C225U-HNI



2MP 25x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 25x optical zoom
> H.265 Encoding
> Starlight technology
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IK10



DAHUA IPC-HF7842F-Z-S2 8MP BOX WizMind Network Camera



IPC-HF7842F-Z-S2



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/24 VAC/PoE power supply, 12 VDC power output, and max. current 165 mA, easy for installation.



DAHUA IPC-HFW5442E-Z4E 4MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5442E-Z4E



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.



DAHUA IPC-HFW5449T1-ZE-LED 4MP Full-color Vari-focal Warm LED Bullet WizMind Network Camera



IPC-HFW5449T1-ZE-LED



> 4MP 1/1.8″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 4MP (2688 × 1520) @30 fps.

> Built-in warm illuminator, and the max. illumination distance is 70 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265,flexible coding, ap plicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker, support two-way talk.

> 12V DC/PoE power supply.

> ePoE, IP67 protection.

> SMD 3.0



DAHUA IPC-HDBW5842E-ZHE 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5842E-ZHE



8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.





DAHUA IPC-HDBW5442H-Z4HE 4MP IR Vari-focal Dome WizMind Network Camera



IPC-HDBW5442H-Z4HE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.



DAHUA SD49216UE-HN 2MP 16x Starlight IR PTZ Lite Network Camera



SD49216UE-HN



2MP 16x Starlight IR PTZ Lite Network Camera

> 1/2.8″ 2Megapixel STARVIS™ CMOS

> Powerful 16x optical zoom

> IR distance up to 100m

> Max. 25/30 fps@1080P

> IP66

> H.265



DAHUA IPC-HFW5442H-Z4HE 4MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5442H-Z4HE



* The parameters and datasheets below can only be applied to 5442- Z-S3 series.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688×1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.



DAHUA IPC-HDBW5842E-Z4E 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera



IPC-HDBW5842E-Z4E



8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/24 VAC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA IPC-HFW5842E-ZHE 8MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5842E-ZHE



8MP IR Vari-focal Bullet WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.





DAHUA IPC-HCBW8442 4MP WizMind Corner Network Camera



IPC-HCBW8442



> 1/1.8” 4Megapixel progressive scan CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> 25/30 fps@2688 × 1520

> WDR (140 dB), Day/Night (ICR), 3D NR, AWB, AGC, BLC

> 2.5 mm fixed lens, distortion correction

> 1/1 Alarm in/out, 1/1 audio in/out

> Max. IR LEDs Length 10 m

> IP67 and IK10+ (50J) protection



DAHUA IPC-HF7842F-Z-X 8MP BOX WizMind Network Camera



IPC-HF7842F-Z-X



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.





DAHUA IPC-HFW5842E-Z4E 8MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5842E-Z4E



8MP IR Vari-focal Bullet WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.

> 12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection.

> SMD 3.0.





DAHUA IPC-EBW8630 6MP Panoramic Network IR Fisheye Camera



IPC-EBW8630



6MP Panoramic Network IR Fisheye Camera

> 1/1.8” 6Megapixel progressive scan STARVIS™ CMOS
> H.265/H.264 triple-stream encoding
> Max 25/30fps@6M(3072×2048)
> Multiple dewarped Mode
> Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Smart detection
> Intelligent Function
> Max. IR LEDs length 10m
> Micro SD memory, IP67, IK10, PoE



DAHUA IPC-HF71242F-Z-X 12MP Box WizMind Network Camera



IPC-HF71242F-Z-X



12MP Box WizMind Network Camera

> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 12 MP (4000 × 3000)@25/30 fps.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.





DAHUA IPC-HFW2431DG-4G-SP-EAU-B 4MP IR Fixed-focal Bullet 4G Solar Power Network Camera



IPC-HFW2431DG-4G-SP-EAU-B



> 4-MP 1/3″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks.

> Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature.

> Built-in 8 GB eMMC memory chip that protects key records from being lost.

> Supports solar power, making it ideal for use in locations that have exposure to sunlight.

> Standalone with built-in solar panel and battery, battery cycle life can last up to 10 days at the rate of 1-hour remote live view per day.

> Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk.

> IP67 protection.



DAHUA IPC-HFW2431DG-4G-SP-LA-B 4MP IR Fixed-focal Bullet 4G Solar Power Network Camera



IPC-HFW2431DG-4G-SP-LA-B



4MP IR Fixed-focal Bullet 4G Solar Power Network Camera

> 4-MP 1/3″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks.

> Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature.

> Built-in 8 GB eMMC memory chip that protects key records from being lost.

> Supports solar power, making it ideal for use in locations that have exposure to sunlight.

> Standalone with built-in solar panel and battery, battery cycle life can last up to 10 days at the rate of 1-hour remote live view per day.

> Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk.

> IP67 protection.





DAHUA IPC-HFW5849T1-ASE-LED 8MP Full-color Fixed-focal Warm LED Bullet WizMind Network Camera



IPC-HFW5849T1-ASE-LED



> 8-MP 1/1.2″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 8 MP (3840 × 2160) @30 fps.

> Built-in warm illuminator, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker; supports two-way talk.

> 12 VDC/PoE power supply.

> ePoE, IP67 protection.

> SMD 3.0.



DAHUA IPC-EBW81230 12MP Panoramic Network IR Fisheye Camera



IPC-EBW81230



> 1/1.7” 12Megapixel progressive scan STARVIS™ CMOS

> H.265/H.264 triple-stream encoding

> Max 25fps@12M(4000×3000)

> Multiple dewarped Mode

> Day/Night(ICR), 3DNR, AWB, AGC, BLC

> Smart detection

> Intelligent Function

> Max. IR LEDs length 10m

> Micro SD memory, IP67, IK10, PoE



DAHUA IPC-HFW71242H-Z-X 12MP IR Bullet WizMind Network Camera



IPC-HFW71242H-Z-X



12MP IR Bullet WizMind Network Camera

> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 12 MP (4000 × 3000)@25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).







DAHUA IPC-HF7442F-Z-X 4MP BOX WizMind Network Camera



IPC-HF7442F-Z-X



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.





DAHUA IPC-HDW5849H-ASE-LED 8MP Full-color Fixed-focal Warm LED Eyeball WizMind Network Camera



IPC-HDW5849H-ASE-LED



> 8-MP 1/1.2″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 8 MP (3840 × 2160) @30 fps.

> Built-in warm light and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic.

> 12 VDC/PoE power supply.

> ePoE, IP67 protection.

> SMD 3.0.



DAHUA IPC-HDBW7842H-Z4-S2 8MP IR Dome WizMind Network Camera



IPC-HDBW7842H-Z4-S2



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 80 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, supports max. 256 G Micro SD card.

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12 VDC power output, max. current 165 mA , easy for installation

> Anti-corrosion coating (optional).



DAHUA IPC-HDBW5441F-AS-E2 2 ¡Á 4 MP Dual-Directional WizMind Network Camera



IPC-HDBW5441F-AS-E2



> Outputs max. 4 MP (2560 × 1440)@25/30 fps.

> Built-in IR LED, and the max. illumination distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding,applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking,applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three people gathering, and parking detection.

> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, and face exposure.

> People counting: Queue management, people counting in area,(day/month/year).

> Dual-channel intelligence can be enabled at the same time and independent of each other.

> Supports dual-channel images previewed in the first channel, saving license costs.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SDcard; built-in MIC.

> 12 VDC/PoE power supply.

> IP67 and IK10.

> SMD 3.0.



DAHUA IPC-HDBW5842H-ZHE 8MP IR Vari-focal Dome WizMind Network Camera



IPC-HDBW5842H-ZHE



8MP IR Vari-focal Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.





DAHUA IPC-HFW5842H-ZHE 8MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5842H-ZHE



8MP IR Vari-focal Bullet WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps. · Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.





DAHUA IPC-HFW3441DG-AS-4G-EAU-B 4MP IR Fixed-focal Bullet WizSense 4G Network Camera



IPC-HFW3441DG-AS-4G-EAU-B



> 4-MP 1/3″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks.

> Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature.

> Built-in 8 GB eMMC memory chip that protects key records from being lost.

> Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS485:1 (Only report the information of solar battery, such as power and battery level), Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk.

> IP67 protection.



DAHUA IPC-HFW3441DG-AS-4G-LA-B 4MP IR Fixed-focal Bullet WizSense 4G Network Camera



IPC-HFW3441DG-AS-4G-LA-B



> 4-MP 1/3″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Built in high-performance 4G Module that suits all mobile networks. Installation is no longer limited to wired networks.

> Built-in PIR sensor that detects human body through passive infrared which is sensitive to body temperature.

> Built-in 8 GB eMMC memory chip that protects key records from being lost.

> Abnormality detection: Motion detection, video tampering, audio detection, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS485:1 (Only report the information of solar battery, such as power and battery level), Supports max. 256 G Micro SD card; built in MIC and speaker; support two-way talk.

> IP67 protection.

> SMD 3.0



DAHUA SD50225U-HNI 2MP 25x Starlight PTZ Network Camera



SD50225U-HNI



2MP 25x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 25x optical zoom
> H.265 Encoding
> Starlight technology
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IP67, IK10



DAHUA IPC-EBW81242-AS-S2 12MP IR Fisheye WizMind Network Camera



IPC-EBW81242-AS-S2



> Outputs max. 12M (4000 × 3000)@25 fps; supports 8M (3280 × 2480)@25/30 fps.
> Built-in IR LED, and the max. illumination distance is 10 m.
> Intelligent monitoring: Intrusion, tripwire, heat map, and people counting
> SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual-array Mic and speaker.
> 12V DC/PoE power supply.
> IP67 and IK10 protection.



DAHUA IPC-HDBW7842H-Z-S2 8MP IR Dome WizMind Network Camera



IPC-HDBW7842H-Z-S2



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 40 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, supports max. 256 G Micro SD card.

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12V DC power output, max. current 165mA , easy for installation

> Anti-corrosion coating(optional)





DAHUA IPC-PFW5849-A180-E2-ASTE 2¡Á4MP Full-color Duo Splicing WizMind Network Camera



IPC-PFW5849-A180-E2-ASTE



> Outputs 180° wide angle splicing image.

> Outputs max. 8 MP (4096 × 1800)@25 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light, and the max. illumination distance is 40 m.

> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card, built-in Mic and speaker, support two-way talk.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> Intelligent monitoring: Intrusion, tripwire, heat map, and people counting.

> EPTZ: Enlarge and track the targets of intelligent alarms.

> SMD.



DAHUA IPC-HDBW7442H-Z4-S2 4MP IR Dome WizMind Network Camera



IPC-HDBW7442H-Z4-S2



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 80 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, supports max. 256 G Micro SD card.

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12 VDC power output, max. current 165mA , easy for installation

> Anti-corrosion coating (optional).



DAHUA SD60225U-HNI 2MP 25x Starlight PTZ Network Camera



SD60225U-HNI



2MP 25x Starlight PTZ Network Camera

>1/2.8” 2Megapixel STARVIS™ CMOS
>Powerful 25x optical zoom
>Starlight technology
>H.265 Encoding
>Max. 50/60fps@1080P, 25/30/50/60fps@720P
>Auto-tracking and IVS
>Support PoE+
>IP67, IK10





DAHUA SD52C430U-HNI 4MP 30x PTZ Network Camera



SD52C430U-HNI



4MP 30x PTZ Network Camera

> 1/3” 4Megapixel CMOS
> Powerful 30x optical zoom
> H.265 Encoding
> Max. 25/30fps@4M/3M, 25/30/50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IK10



DAHUA IPC-HFW7442H-Z4-S2 DAHUA IPC-HFW7442H-Z-S2 4MP IR Bullet WizMind Network Camera



IPC-HFW7442H-Z4-S2



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 120 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection, etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12V DC power output, max. current 165mA , easy for installation

> Anti-corrosion coating (optional).



DAHUA IPC-HDBW5842H-Z4HE 8MP IR Vari-focal Dome WizMind Network Camera



IPC-HDBW5842H-Z4HE



8MP IR Vari-focal Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.





DAHUA IPC-HFW7842H-Z4-S2 8MP IR Bullet WizMind Network Camera



IPC-HFW7842H-Z4-S2



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 120 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12V DC power output, max. current 165 mA , easy for installation

> Anti-corrosion coating(optional).



DAHUA IPC-HFW7442H-Z4-S2 4MP IR Bullet WizMind Network Camera



IPC-HFW7442H-Z4-S2



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 120 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection, etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12V DC power output, max. current 165mA , easy for installation

> Anti-corrosion coating (optional).



DAHUA IPC-HFW5842H-Z4HE 8MP IR Vari-focal Bullet WizMind Network Camera



IPC-HFW5842H-Z4HE



8MP IR Vari-focal Bullet WizMind Network Camera

* The parameters and datasheets below can only be applied to 5842- Z-S3 series.

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840×2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual MICs.

> 24 VAC/12 VDC/PoE power supply; ePoE.

> IP67 and IK10 protection, heater.

> SMD 3.0.

> Anti-corrosion model optional.





DAHUA SD50430U-HNI 4MP 30x PTZ Network Camera



SD50430U-HNI



4MP 30x PTZ Network Camera

> 1/3” 4Megapixel CMOS
> Powerful 30x optical zoom
> H.265 Encoding
> Max. 25/30fps@4M/3M, 25/30/50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IP67, IK10



DAHUA IPC-HFW7842H-Z4-S2 DAHUA IPC-HFW7842H-Z-S2 8MP IR Bullet WizMind Network Camera



IPC-HFW7842H-Z4-S2



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 120 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12V DC power output, max. current 165 mA , easy for installation

> Anti-corrosion coating(optional).



DAHUA SD59225U-HNI 2MP 25x Starlight IR PTZ Network Camera



SD59225U-HNI



2MP 25x Starlight IR PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 25x optical zoom
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IR distance up to 150m
> IP66





DAHUA IPC-EBW8842-AS 8MP IR Fisheye WizMind Network Camera



IPC-EBW8842-AS



> Outputs max. 8M (3280 × 2480) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 10 m.
> Intelligent monitoring: Intrusion, tripwire, heat map, and people counting.
> SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual-array Mic and speaker
> 12V DC/PoE power supply.
> IP67 and IK10 protection.



DAHUA IPC-HDBW8841H-Z-LB 8MP WizMind Classroom Network Camera



IPC-HDBW8841H-Z-LB



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> Supports Classroom Behavior Analysis, including detection of abnormal number of people (for tracking teachers), standing, writing on the blackboard, back turned to students, head up, and walking.

> Supports Exam Behavior Analysis, including detection of students looking around and passing objects between each other.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals in the classroom, adaptively reduce noise, and filter non-human voices.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 30 meters when used indoors.

> Supports two-way talk.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; built-in dual MICs, RS-485, BNC; supports max. 256 G Micro SD card.

> 24 VAC/12 VDC/PoE power supply, 12 VDC power output, and max. current 165 mA, easy for installation.

> 5 streams for 3-channel HD video display.

> IP67 and IK10 protection.



DAHUA IPC-HDBW8841H-Z4-LB 8MP WizMind Classroom Network Camera



IPC-HDBW8841H-Z4-LB



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> Supports Classroom Behavior Analysis, including detection of abnormal number of people (for tracking teachers), standing, writing on the blackboard, back turned to students, head up, and walking.

> Supports Exam Behavior Analysis, including detection of students looking around and passing objects between each other.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals in the classroom, adaptively reduce noise, and filter non-human voices.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 30 meters when used indoors.

> Supports two-way talk.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; built-in dual MICs, RS-485, BNC; supports max. 256 G Micro SD card.

> 24 VAC/12 VDC/PoE power supply, 12 VDC power output, and max. current 165 mA, easy for installation.

> 5 streams for 3-channel HD video display.

> IP67 and IK10 protection.



DAHUA IPC-HFW7442H-Z-X 4MP IR Bullet WizMind Network Camera



IPC-HFW7442H-Z-X



4MP IR Bullet WizMind Network Camera

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-Corrosion coating(optional).





DAHUA IPC-HDBW7442E1-Z-X 4MP IR Dome WizMind Network CAMERA



IPC-HDBW7442E1-Z-X



4MP IR Dome WizMind Network CAMERA

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).





DAHUA IPC-MFW7842K1-Z4-T20 8+2 MP Dual-Sight Bullet WizMind Network Camera



IPC-MFW7842K1-Z4-T20



> 8-MP 1/1.7″ CMOS image sensor and 2-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> Built-in GPU chip and deep learning algorithm, which can improve the detection accuracy.

> Switch among five intelligent resources: IVS, face detection, video metadata, people counting and face recognition.

> Built-in warm light/IR LED that has a maximum IR illumination distance of 100 m and warm light distance of 60 m.

> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.

> Designed with the Dahua Noise Reduction Algorithm and built-in dual microphones, the device performs active noise control, eliminating noise of wind scale 3. It has a pick-up distance up to 20 m.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 30 m when used indoors.

> Sound and light alarms are generated when an alarm is triggered.

> 12 VDC/PoE power supply, 12 VDC power output, max. current 165 mA, easy for installation.

> IP67 protection.





DAHUA IPC-HFW7842H-Z-X 8MP IR Bullet WizMind Network Camera



IPC-HFW7842H-Z-X



8MP IR Bullet WizMind Network Camera

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-Corrosion coating(optional).





DAHUA IPC-HDBW7842E1-Z-X 8MP IR Dome WizMind Network CAMERA



IPC-HDBW7842E1-Z-X



8MP IR Dome WizMind Network CAMERA

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection:Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).





DAHUA IPC-HDBW7442E1-Z4-X 4MP IR Dome WizMind Network Camera



IPC-HDBW7442E1-Z4-X



4MP IR Dome WizMind Network Camera

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).





DAHUA IPC-EB81242-PD Parking Space Detection Fisheye WizMind Network Camera



IPC-EB81242-PD



Parking Space Detection Fisheye WizMind Network Camera

> Built-in GPU chip and deep learning algorithm, which can improve the detection accuracy.
> Support up to 12 parking space status detection.
> 360° panoramic view without dead angles in its monitoring range, making it cost-effective.
> Outputs max. 3008 × 3000@20 fps.
> 7 indicator colors that can be customized to display the status of parking spaces.
> H.265 codec, high compression rate, ultra-low bit rate.
> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> DWDR, ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; 485; BNC; supports max. 256 G Micro SD card.
> 12 VDC/PoE power supply, 12 VDC power output, and max. current 165 mA, easy for installation.
> IP67 protection.



DAHUA IPC-MFW7442K1-Z4-T40 4+4 MP Dual-Sight Bullet WizMind Network Camera



IPC-MFW7442K1-Z4-T40



> 4-MP 1/1.7″ CMOS image sensor and 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> Built-in GPU chip and deep learning algorithm, which can improve the detection accuracy.

> Switch among five intelligent resources: IVS, face detection, video metadata, people counting and face recognition, Channel 1 support only.

> Built-in warm light/IR LED that has a maximum IR illumination distance of 100 m and warm light distance of 60 m.

> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.

> Designed with the Dahua Noise Reduction Algorithm and built-in dual microphones, the device performs active noise control, eliminating noise of wind scale 3. It has a pick-up distance up to 20 m.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 30 m when used indoors.

> Sound and light alarms are generated when an alarm is triggered.

> 12 VDC/PoE power supply, 12 VDC power output, max. current 165 mA, easy for installation.

> IP67 protection.



DAHUA SDZW2000T-SL 2MP Anti-corrosion IR Network Camera



SDZW2000T-SL



2MP Anti-corrosion IR Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> IVS
> IP68, IK10, NEMA 4X

> Material: 316L Stainless Steel



DAHUA IPC-HFW7842H-Z4-X 8MP IR Bullet WizMind Network Camera



IPC-HFW7842H-Z4-X



8MP IR Bullet WizMind Network Camera

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 120 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection.

> Anti-Corrosion coating(optional).





DAHUA IPC-HDBW7842E1-Z4-X 8MP IR Dome WizMind Network CAMERA



IPC-HDBW7842E1-Z4-X



8MP IR Dome WizMind Network CAMERA

> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@50/60 fps.

> Built-in IR LED, and the max. illumination distance is 80 m.

> ROI, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).





DAHUA IPC-HDBW71242E1-Z-X 12MP IR Dome WizMind Network Camera



IPC-HDBW71242E1-Z-X



12MP IR Dome WizMind Network Camera

> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 12 MP (4000 × 3000)@25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.

> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.

> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.

> Built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.

> IP67 and IK10 protection, Anti-Corrosion coating (optional).





DAHUA IPC-MFW7442K1-Z7-T40 4+4MP Dual-Sight Bullet WizMind Network Camera



IPC-MFW7442K1-Z7-T40



> 4-MP 1/1.7″ CMOS image sensor and 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> Built-in GPU chip and deep learning algorithm, which can improve the detection accuracy.

> Switch among five intelligent resources: IVS, face detection, video metadata, people counting and face recognition.

> Built-in warm light/IR LED that has a maximum IR illumination distance of 120 m and warm light distance of 80 m.

> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC;supports max. 256 G Micro SD card.

> Designed with the Dahua Noise Reduction Algorithm and built-in dual microphones, the device performs active noise control, eliminating noise of wind scale 3. It has a pick-up distance up to 20 m.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 30 m when used indoors.

> Sound and light alarms are generated when an alarm is triggered.

> 12 VDC/PoE power supply, 12 VDC power output, max. current 165 mA, easy for installation.

> IP67 protection.



DAHUA SD60230U-HNI 2MP 30x Starlight PTZ Network Camera



SD60230U-HNI



2MP 30x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P, 25/30/50/60fps@720P
> Auto-tracking and IVS
> Support PoE+
> IP67, IK10





DAHUA SD50230U-HNI 2MP 30x Starlight PTZ Network Camera



SD50230U-HNI



2MP 30x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+

> IP67, IK10



DAHUA IPC-MFW7842K1-Z7-T20 8+2 MP Dual-Sight Bullet WizMind Network Camera



IPC-MFW7842K1-Z7-T20



> 8-MP 1/1.7″ CMOS image sensor and 2-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> Built-in GPU chip and deep learning algorithm, which can improve the detection accuracy.

> Switch among five intelligent resources: IVS, face detection, video metadata, people counting and face recognition.

> Built-in warm light/IR LED that has a maximum IR illumination distance of 120 m and warm light distance of 80 m.

> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.

> Designed with the Dahua Noise Reduction Algorithm and built-in dual microphones, the device performs active noise control, eliminating noise of wind scale 3. It has a pick-up distance up to 20 m.

> Built-in Hi-Fi large-diameter speaker covers an auditory range of 30 meters when used indoors.

> Sound and light alarms are generated when an alarm is triggered.

> 12 VDC/PoE power supply, 12 VDC power output, max. current 165 mA, easy for installation.

> IP67 protection.



DAHUA SDZ4032-HNR-ZB 4MP 32x Starlight Zoom Network Camera



SDZ4032-HNR-ZB



4MP 32x Starlight Zoom Network Camera

> 32x optical zoom
> Starlight technology
> H.265 encoding
> Perimeter protection
> Face detection
> Smart capture
> Supports PoE



DAHUA IPC-PFW81642-A180 4 ¡Á 4 MP Multi-Sensor Panoramic Bullet Wizmind Network Camera



IPC-PFW81642-A180



> Outputs max. 16 MP (5520 × 2700)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Three streams for HD video display.
> Built-in IR LED, and the max. illumination distance is 30 m.
> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.
> 12 VDC/24 VAC/PoE power supply, easy for installation.
> IP67 and IK10 protection.



DAHUA ECA3A1804-HNR-XB 8MP Explosion-proof IR Bullet WizMind Network Camera

ECA3A1804-HNR-XB



8MP Explosion-proof IR Bullet WizMind Network Camera

> 8-MP 1/2.8″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 8 MP (3840 × 2160) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports: face detection, perimeter protection, people counting, heat map, SMD4.0.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS-485; supports max. 512 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> 304/316L stainless steel casing, 2 m cable.

> IP68 protection.



DAHUA SD6CE245U-HNI 2MP 45x Starlight IR PTZ Network Camera



SD6CE245U-HNI



2MP 45x Starlight IR PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 45x optical zoom
> Starlight technology
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> IR distance up to 250m
> Support PoE+
> IP67, IK10





DAHUA IPC-PDBW5831-B360 4 ¡Á 2 MP 4-Directional Panoramic Dome Network Camera



IPC-PDBW5831-B360



4 × 2 MP 4-Directional Panoramic Dome Network Camera

> Four 1/2.8” 2Megapixel progressive scan STARVIS^TM CMOS
> H.265&H.264 dual-stream encoding
> 25/30fps@2M(1920×1080)
> Smart Detection supported
> WDR(140dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm~12mm motorized lens
> Max. IR LEDs Length 30m
> Micro SD memory, IP67, IK10, PoE+



DAHUA SD52C230U-HNI 2MP 30x Starlight PTZ Network Camera



SD52C230U-HNI



2MP 30x Starlight PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 30x optical zoom
> Starlight technology
> H.265 Encoding
> Max. 50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IK10



DAHUA IPC-EBW81242-AS-IVC-S2 12MP IR Fisheye WizMind Network Camera with Panomorph Lens



IPC-EBW81242-AS-IVC-S2



> Outputs max. 12M (4000 × 3000)@25 fps; supports 8M (3280 × 2480)@25/30 fps
> Built-in IR LED, and the max. illumination distance is 10 m.
> Intelligent monitoring: Intrusion, tripwire, heat map, and people counting
> SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual-array Mic and speaker
> 12V DC/PoE power supply.
> IP67 and IK10 protection.
> Adopts Panomorph lens, having better compatibility with third party platform
> Panomorph Lens RPL: B9VVT.



DAHUA IPC-PDBW82041-B360-S2 4 ¡Á 5 MP 4-Directional Panoramic Dome Wizmind Network Camera



IPC-PDBW82041-B360-S2



> 4-channel stream output, and each channel can output max. 5 MP (2592 × 1944) @25/30 fps.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> The intelligent functions of 4 channels can be enabled at the same time, including face detection, IVS, and people counting.
> Intelligent detection: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human), abandoned object, missing object, loitering detection, people gathering, and parking detection.
> FlexStream: The 4 channels of images can be viewed in a defined channel with 1 channel stream. That is the multiple images can be displayed in 1 channel.
> Web5.0 interface design, which is friendly to users, and easy for operation.
> Built-in IR LED illuminator, and the max. illumination distance is 30 m.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; supports max. 256 G Micro SD card.
> 12 VDC/PoE power supply; 12 VDC power output, and max. current 165mA; easy for installation.
> IP67 and IK10 protection.
> Anti-corrosion protection (optional).



DAHUA IPC-HDBW8232E-Z-SL 2MP Starlight Anti-Corrosion IR Dome Network Camera

IPC-HDBW8232E-Z-SL



2MP Starlight Anti-Corrosion IR Dome Network Camera

> 1/1.8” 2Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@1080P(1920×1080)
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 4.1mm ~16.4mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory,IP67,IK10,POE+
> 316L stainless steel housing





DAHUA SD60430U-HNI 4MP 30x PTZ Network Camera



SD60430U-HNI



4MP 30x PTZ Network Camera

> 1/3” 4Megapixel CMOS
> Powerful 30x optical zoom
> H.265 Encoding
> Max. 25/30fps@4M/3M, 25/30/50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IP67, IK10





DAHUA SD6AL245U-HNI-IR 2MP 45x Starlight IR PTZ Network Camera



SD6AL245U-HNI-IR



2MP 45x Starlight IR PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 45x optical zoom
> Max. 50/60fps@1080P
> Auto tracking and IVS
> Support Hi-PoE
> IR distance up to 300m
> IP67





DAHUA IPC-HDEW8441R-Z 4MP Explosion Proof IR Dome WizMind Network Camera



IPC-HDEW8441R-Z



* The parameters and datasheets below can only be applied to 8441-S2 series.

> 4-MP 1/3.0″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Supports the AFSA(Anti-flicker Self-adaption) function, which automatically eliminates flicker.

> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, face exposure, and face attributes.

> People counting: People counting in area, queue management, and entered/exited people counting; generating and exporting report (day/ month/year).

> Intelligent monitoring: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human). abandoned object, missing object, loitering detection, people gathering, parking detection, heat map, and face detection.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> IP68 and IK10 protection.

> Explosion-proof mark II 2 G Ex db IIC T6/T5 Gb; II 2 D Ex tb IIIC T80°C/ T100°C Db.

> 316 stainless steel casing, 2 m cable.

> ATEX and IECEx Certifacation.

> SMD 3.0.



DAHUA IPC-HDEW8841R-Z 4MP Explosion Proof IR Dome WizMind Network Camera



IPC-HDEW8841R-Z



8MP Explosion Proof IR Dome WizMind Network Camera

* The parameters and datasheets below can only be applied to 8841-S2 series.

> 8-MP 1/2.8″ CMOS image sensor, low illuminance, high image definition.

> Outputs max. 8 MP (3840 × 2160) @25/30 fps.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Supports the AFSA(Anti-flicker Self-adaption) function, which automatically eliminates flicker.

> Face detection: Track, snapshot, snapshot optimization, optimal face snapshot upload, face enhancement, face exposure, and face attributes.

> People counting: People counting in area, queue management, and entered/exited people counting; generating and exporting report (day/ month/year).

> Intelligent monitoring: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human), abandoned object, missing object, loitering detection, people gathering, parking detection, heat map, and face detection.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> IP68 and IK10 protection.

> Explosion-proof mark II 2 G Ex db IIC T6/T5 Gb; II 2 D Ex tb IIIC T80°C/ T100°C Db.

> 316 stainless steel casing, 2 m cable.

> ATEX and IECEx Certifacation.

> SMD 3.0.



DAHUA IPC-HFW5842DK1-Z-5G Dahua 8MP 5G Vari-focal Bullet WizMind Network Camera



IPC-HFW5842DK1-Z-5G



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED, and the max. illumination of IR distance is 60 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, supports max. 512 G Micro SD card; built-in dual MICS and speaker, support two-way talk.

> 12 VDC power supply.

> 12 VDC power output, and max. current 165 mA, easy for installation.

> Supports multiple frequency bands for 5G that make it convenient to install and connect to the network.

> IP67 Protection.

> SMD 4.0.



DAHUA IPC-HFW5842DK1-Z4-5G Dahua 8MP 5G Vari-focal Bullet WizMind Network Camera



IPC-HFW5842DK1-Z4-5G



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light/IR LED, and the max. illumination of IR distance is 120 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, supports max. 512 G Micro SD card; built in dual MICs and speaker.

> 12 VDC power supply.

> 12 VDC power output, and max. current 165 mA, easy for installation.

> Supports multiple frequency bands for 5G that make it convenient to install and connect to the network.

> IP67 Protection.

> SMD 4.0



DAHUA IPC-EBW8842-AS-IVC 8MP IR Fisheye WizMind Network Camera with Panomorph Lens



IPC-EBW8842-AS-IVC



> Outputs max. 8M (3280 × 2480) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 10 m.
> Intelligent monitoring: Intrusion, tripwire, heat map, and people counting.
> SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual-array Mic and speaker
> 12V DC/PoE power supply.
> IP67 and IK10 protection.
> Adopts Panomorph lens, having better compatibility with third party platform.
> Panomorph Lens RPL: B9VVT.



DAHUA IPC-PFW83242-A180-S2 4 ¡Á 8 MP Multi-Sensor Panoramic Bullet WizMind Network Camera



IPC-PFW83242-A180-S2



> 4 × 8MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 32MP (8192 × 3840) @25/30 fps; with intelligent functions enabled, it can output 32MP (8192 × 3840) @20 fps

> Built-in IR LED, and the max. illumination distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Intelligent functions: Crowd Distribution Map, Vehicle Density, Perimeter Protection, EPTZ.

> Support image correction.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; 485; BNC; supports max. 256G SD card.

> 12 VDC/24 VAC/PoE power supply; easy for installation

> IP67 and IK10 protection

> AR panorama technology; various AR tags can be overlaid.



DAHUA IPC-MFW7449Y-Z7-T44 4+4MP Dual-Sight Polarlight Bullet WizMind Network Camera



IPC-MFW7449Y-Z7-T44



> 2 lenses and 2 channels are integrated into the design.

> Adopts advanced technologies such as Hyper DoF, Illumination by Area, to achieve full coverage of different speed targets with a larger DoF distance under low illumination.

> Flexible remote debugging through the Dual-micro PTZ.

> Dual channels: 4-MP 1/1.8″ CMOS image sensors, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30fps.

> Built-in efficient illuminator of dual light fusion, and the max. illumination distance is 150 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Multiple intelligent resources switchable.

> Channel 1: IVS, Face recognition, Face detection and Video metadata,

> Channel 2: IVS, Face recognition, Face detection, Video metadata, Crowd distribution map and People counting.

> Intelligent functions of Channel 1 and Channel 2 can be enabled at the same time.

> Hyper DoF technology: DoF and iris of the camera can be adjusted separately. With the largest iris, the camera can display the image of large DoF.

> Time-Division Exposure that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> Alarm: 7 in, 3 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G Micro SD card.

> 12 VDC power supply, easy for installation.

> IP67 protection.



DAHUA SD6AL245U-HNI 2MP 45x Starlight Laser PTZ Network Camera



SD6AL245U-HNI



2MP 45x Starlight Laser PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS
> Powerful 45x optical zoom
> Max. 50/60fps@1080P
> Auto tracking and IVS
> Support Hi-PoE
> IR distance up to 550m
> IP67





DAHUA IPC-MFW7449Y-Z7-T8A 4+8MP Dual-Sight Polarlight Bullet WizMind Network Camera



IPC-MFW7449Y-Z7-T8A



> 3 lenses and 2 channels are integrated into the design.

> Adopts advanced technologies such as Hyper DoF, Illumination by Area, to achieve full coverage of different speed targets with a larger DoF distance under low illumination.

> Flexible remote debugging through the Dual-micro PTZ.

> Two channels: Channel 1: 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image. Channel 2: Dual 4-MP 1/1.8″ CMOS image sensors, low luminance, and high definition image.

> Outputs max. 8 MP (4976 × 1450)@25/30 fps.

> Built-in efficient illuminator of dual light fusion, and the max. illumination distance is 150 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Multiple intelligent resources switchable: Channel 1: IVS, face recognition, face detection and video metadata. Channel 2: IVS, crowd distribution map and People counting.

> Intelligent functions of Channel 1 and Channel 2 can be enabled at the same time. (except Video metadata & Crowd distribution map).

> Hyper DoF technology: DoF and iris of the camera can be adjusted separately. With the largest iris, the camera can display the image of large DoF.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> Panoramic splicing: up to 180° panoramic angle meets the requirement of broad scenarios.

> Alarm: 7 in, 3 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G Micro SD card.

> 12 VDC power supply, easy for installation.

> IP67 protection.



DAHUA IPC-HFS8449G-Z7-LED 4MP High Temperature Tolerance WizMind Network Camera



IPC-HFS8449G-Z7-LED



> The intelligent temperature control system automatically opens and closes based on the ambient temperature, making the device suitable for environments with high-temperatures such as steel plants and boiler plants.

> Works 24/7 in an environment that is 75°C (167°F), and works continuously for 12 hours in 85°C (185°F).

> Hyper DoF technology: DoF and iris of the camera can be adjusted separately. With the largest iris, the camera can display the image of large DoF.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> Ghosting Diminishment: Motion blur does not occur when objects are moving at night with WDR enabled.

> Built-in GPU chips and deep learning algorithm, which can improve the detection accuracy.

> Five switchable intelligent resources: Video Metadata, face detection, face recognition, face statistics and perimeter protection.

> Five streams for three-channel HD video display.

> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.

> 100–240 VAC power supply, easy for installation.

> IP67 protection.



DAHUA IPC-MFW7849Y-Z4-T44 8+4MP Dual-Sight Polarlight Bullet WizMind Network Camera



IPC-MFW7849Y-Z4-T44



> 2 lenses and 2 channels are integrated into the design.

> Adopts advanced technologies such as Hyper DoF, Illumination by Area, to achieve full coverage of different speed targets with a larger DoF distance under low illumination.

> Flexible remote debugging through the Dual-micro PTZ.

> Dual channels: Channel 1: 8-MP 1/1.2″ CMOS image sensor, low luminance, and high definition image. Channel 2: 4-MP 1/1.8″ CMOS image sensors, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> Built-in efficient illuminator of dual light fusion, and the max. illumination distance is 120 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Multiple intelligent resources switchable: Channel 1: IVS, Face recognition, Face detection and Video metadata, Channel 2: IVS, Face recognition, Face detection, Video metadata, Crowd distribution map and People counting.

> Intelligent functions of Channel 1 and Channel 2 can be enabled at the same time.

> Hyper DoF technology: DoF and iris of the camera can be adjusted separately. With the largest iris, the camera can display the image of large DoF.

> Time-Division Exposure ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> Alarm: 7 in, 3 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G Micro SD card.

> 12 VDC power supply, easy for installation.

> IP67 protection.



DAHUA IPC-MFW7849Y-Z4-T8A 8+8MP Dual-Sight Polarlight Bullet WizMind Network Camera



IPC-MFW7849Y-Z4-T8A



> 3 lenses and 2 channels are integrated into the design.

> Adopts advanced technologies such as Hyper DoF, Illumination by Area, to achieve full coverage of different speed targets with a larger DoF distance under low illumination.

> Flexible remote debugging through the Dual-micro PTZ.

> Two channels: Channel 1: 8-MP 1/1.2″ CMOS image sensor, low luminance, and high definition image. Channel 2: Dual 4-MP 1/1.8″ CMOS image sensors, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Multiple intelligent resources switchable: Channel 1: IVS, face recognition, face detection and video metadata. Channel 2: IVS, crowd distribution map and People counting.

> Intelligent functions of Channel 1 and Channel 2 can be enabled at the same time. (except Video metadata & Crowd distribution map).

> Hyper DoF technology: DoF and iris of the camera can be adjusted separately. With the largest iris, the camera can display the image of large DoF.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> Panoramic splicing: up to 180° panoramic angle meets the requirement of broad scenarios.

> Alarm: 7 in, 3 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G Micro SD card.

> 12 VDC power supply, easy for installation.

> IP67 protection.



CCTV-MALL SD8A840XA-HNP-WP 8MP 40x Starlight WizMind Hydrological Monitoring Network Camera



SD8A840XA-HNP-WP



8MP 40x Starlight WizMind Hydrological Monitoring Network Camera

> 1/1.8″ 8Megapixel STARVIS™ CMOS
> Powerful 40x optical zoom
> IR distance up to 250 m
> Max. 25/30 fps@4K
> Water level marker detection and calibration
> Water level marker joining
> Boat detection
> IP67



DAHUA SD8A840XA-HNP-WP 8MP 40x Starlight WizMind Hydrological Monitoring Network Camera



SD8A840XA-HNP-WP



> Powerful 40x optical zoom
> IR distance up to 250 m
> Max. 25/30 fps@4K
> Water level marker detection and calibration
> Water level marker joining
> Boat detection
> IP67



DAHUA SD8A840-HNF-PA 8MP 40x Starlight IR PTZ AI Network Camera



SD8A840-HNF-PA



> Powerful 40x optical zoom
> Starlight technology
> Perimeter protection
> Metadata
> Face Recognition
> Auto-tracking
> Smart wiper
> IP67



DAHUA IPC-HFS8849G-Z3-LED 8MP High Temperature Tolerance WizMind Network Camera



IPC-HFS8849G-Z3-LED



> The intelligent temperature control system automatically opens and closes based on the ambient temperature, making the device suitable for environments with high-temperatures such as steel plants and boiler plants.

> Works 24/7 in an environment that is 75°C (167°F), and works continuously for 12 hours in 85°C (185°F).

> Hyper DoF technology: DoF and iris of the camera can be adjusted separately. With the largest iris, the camera can display the image of large DoF.

> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.

> Built-in GPU chips and deep learning algorithm, which can improve the detection accuracy.

> Five switchable intelligent resources: Video Metadata, face detection, face recognition, face statistics and perimeter protection.

> Five streams for three-channel HD video display.

> 8-MP 1/1.2″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.

> 100–240 VAC power supply, easy for installation.

> IP67 protection.



DAHUA SD8A440-HNF-PA(onlyforUAE) 4MP 40x Starlight IR PTZ AI Network Camera



SD8A440-HNF-PA(only for UAE)



4MP 40x Starlight IR PTZ AI Network Camera

> 1/1.8″ 4Megapixel STARVIS™ CMOS
> Powerful 40x optical zoom
> Starlight+ technology
> Perimeter protection
> Metadata
> Face Recognition
> Auto-tracking
> Smart wiper

> IP67



DAHUA SD8A440-HNF-PA 4MP 40x Starlight IR PTZ AI Network Camera

SD8A440-HNF-PA



4MP 40x Starlight IR PTZ AI Network Camera

> 1/1.8″ 4Megapixel STARVIS™ CMOS
> Powerful 40x optical zoom
> Starlight+ technology
> Perimeter protection
> Metadata
> Face Recognition
> Auto-tracking
> Smart wiper

> IP67



DAHUA PSDW8842S-A180-D425 8 MP Multi-Sensor 180¡ã Panoramic PTZ Mini Hubble Wizmind Network Camera



PSDW8842S-A180-D425



> Panoramic parameters: 4 × 2 MP 1/1.8″ CMOS image sensors.

PTZ parameters: 1 × 4 MP 1/1.8″ CMOS image sensors.

> PTZ camera: Built-in laser illuminator, max. illumination distance: 100 m.

> H.265 codec, high compression rate, ultra-low bit rate.

> WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Smart tracking.

> Built-in dual MICs, built-in speaker, support two way-talk.

> Intelligent Functions: Panoramic Network Camera: Perimeter Protection; PTZ Camera: Perimeter Protection, Face Detection and Video Metadata.



DAHUA SD8A440-HNT-WA 4MP 40x Starlight WizMind Traffic Parking Network Camera

SD8A440-HNT-WA



4MP 40x Starlight WizMind Traffic Parking Network Camera

> 1/1.8″ 4Megapixel STARVIS™ CMOS

> Powerful 40x optical zoom

> Starlight technology

> Max. 2560 × 1440@30 fps

> Automatically captures pictures of illegal parking events in the specified area

> Built-in ANPR engine, equipped with deep learning algorithm application

> Supports multiple tour modes to improve capture efficiency

> Supports connecting the speaker to use reminder functions such as voice broadcast of license plate number, and voice talk

> Continuous 360° horizontal rotation, –30° to 90° vertical rotation, and auto flip 180°; no blind zone

> IP67

> IR distance up to 500 m

> Auto-iris



DAHUA PSDW81642S-A360-D425 16 MP Multi-Sensor 360¡ã Panoramic PTZ Mini Hubble Wizmind Network Camera



PSDW81642S-A360-D425



> Panoramic parameters: 8 × 2 MP 1/1.8″ CMOS image sensors.

PTZ parameters: 1 × 4 MP 1/1.8″ CMOS image sensors.

> PTZ camera: Built-in laser illuminator, max. illumination distance: 100 m.

> PTZ camera: 25x optical zoom,16x digital zoom.

> H.265 codec, high compression rate, ultra-low bit rate.

> 3D NR, HLC, BLC, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Smart tracking.

> Built-in dual MICs and dual speakers, support two way-talk.

> Intelligent Functions: Panoramic Network Camera: Perimeter Protection; PTZ Camera: Perimeter Protection, Face Detection and Video Metadata.



DAHUA PSDW81642M-A180-D440-S3 16 MP Multi-Sensor 180¡ã Panoramic PTZ Hubble WizMind Network Camera



PSDW81642M-A180-D440-S3



> Channel 1 (Panoramic): 4 × 4 MP 1/1.8″ CMOS image sensors. Field of View:Horizontal: 1 × 180°: Vertical: 103°. Channel 2 (PTZ): 1 × 4 MP 1/1.8″ CMOS image sensors.

> Channel 2 (PTZ): 40x optical zoom, 16x digital zoom.

> Channel 2 (PTZ): Illumination distance up to 400 m.

> Channel 1 (Panoramic): Three switchable intelligent resources: Perimeter protection, crowd map, vehicle density.

> Channel 2 (PTZ): Three switchable intelligent resources:Perimeter protection, video metadata, face recognition.

> AR panorama technology; various AR tags can be overlaid.

> Smart tracking. GPS/BDS positioning.

> Smart H265+/H264+ encoding.

> WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.

> Alarm: 7 in, 3 out; audio: 2 in, 2 out; 1 channel BNC, 1 channel RS–485 (baud rate can be set). supports max. 512 G SD card.



DAHUA PSDW82442M-A270-D440-S3 24 MP Multi-Sensor 270¡ã Panoramic PTZ Hubble WizMind Network Camera



PSDW82442M-A270-D440-S3



> Channel 1 (Panoramic): 6 × 4 MP 1/1.8″ CMOS image sensors. Field of View:Horizontal: 1 × 270°, Vertical: 103°. Channel 2 (PTZ): 1 × 4 MP 1/1.8″ CMOS image sensors.

> Channel 2 (PTZ): 40x optical zoom,16x digital zoom.

> Channel 2 (PTZ): Illumination distance up to 400 m.

> Channel 1 (Panoramic): Three switchable intelligent resources: Perimeter protection, Crowd map, Vehicle density.

> Channel 2 (PTZ): Three switchable intelligent resources: Perimeter protection, Video metadata, Face recognition.

> AR panorama technology; various AR tags can be overlaid.

> Smart tracking. GPS/BDS positioning.

> Smart H265+/H264+ encoding.

> WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.

> Alarm: 7 in, 3 out; audio: 2 in, 2 out; 1 channel BNC, 1 channel RS–485 (baud rate can be set). supports max. 512 G SD card.



DAHUA PSDW81642M-A360-D440-S3 16 MP Multi-Sensor 360¡ã Panoramic PTZ Hubble WizMind Network Camera



PSDW81642M-A360-D440-S3



> Channel 1 (Panoramic): 8 × 2 MP 1/1.8″ CMOS image sensors. Field of View:Horizontal: 1 × 360°, Vertical: 103°. Channel 2 (PTZ): 1 × 4 MP 1/1.8″ CMOS image sensors.

> Channel 2 (PTZ): 40x optical zoom, 16x digital zoom.

> Channel 2 (PTZ): Illumination distance up to 400 m.

> Channel 1 (Panoramic): Three switchable intelligent resources: Perimeter protection, Crowd map, Vehicle density.

> Channel 2 (PTZ): Three switchable intelligent resources: Perimeter protection, Video metadata, Face recognition.

> AR panorama technology; various AR tags can be overlaid.

> Smart tracking. GPS/BDS positioning.

> Smart H265+/H264+ encoding.

> WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.

> Alarm: 7 in, 3 out; audio: 2 in, 2 out; 1 channel BNC, 1 channel RS–485 (baud rate can be set). supports max. 512 G SD card.



DAHUA PSDW83242M-A360-D845L-S3 32 MP Multi-Sensor 360¡ã Panoramic PTZ Hubble WizMind Network Camera



PSDW83242M-A360-D845L-S3



> Panoramic parameters: 8 × 4 MP 1/1.8″ CMOS image sensors. Outputs max. 32 MP (11520 × 2700)@25/30 fps.

> PTZ parameters: 1 × 8 MP 1/1.8″ CMOS image sensors. Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> PTZ camera: Built-in illuminators (2 × IR and 7 × laser), max. illumination distance: 500 m.

> PTZ camera: 45x optical zoom,16x digital zoom.

> H.265 codec, high compression rate, ultra-low bit rate.

> 3D NR, HLC, BLC, applicable to various monitoring scenes.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Alarm: 7 in, 3 out; audio: 2 in, 2 out; RS-485; BNC; supports max. 512 G SD card.

> Intelligent Functions:PTZ Camera: Perimeter Protection, Face Recognition and Video Metadata.

> GPS/BDS positioning.



DAHUA SDT8C842-8P-FA-APV-0280 4MP Starlight IR WizMind Network Dual-PTZ Camera



SDT8C842-8P-FA-APV-0280



8MP 42x Starlight Dual Light Network Panoramic PTZ Camera

> Panorama: 2 × 4 MP 1/1.8″ CMOS image sensor; Detail: 8MP 1/1.8″ CMOS image sensor.

> 42 x optical zoom.

> Max. 25/30fps@4K.

> IR distance up to 300 m.

> Auto tracking.

> Perimeter protection.

> Face detection.

> Wiper.

> IP67.

> Sound and light alarm.

> PoE++(802.3bt).



DAHUA SDT5X425-4Z4-FAJG-PV-0832 4MP 25x Starlight IR WizMind Network Dual-PTZ Camera for Traffic



SDT5X425-4Z4-FAJG-PV-0832



4MP 25x Starlight IR WizMind Network Dual-PTZ Camera for Traffic

> Dual PTZ system, dual vari-focal lens.

> 1/1.8″ 4Megapixel CMOS.

> Powerful 25x optical zoom.

> Starlight technology.

> Max. 25/30 fps@4M.

> H.265 encoding.

> IP67.

> Illegal parking detection and checkpoint capture.



DAHUA SDT5X425-4Z4-FAJG-2812 4MP 25x Starlight IR WizMind Network Dual-PTZ Camera for Traffic



SDT5X425-4Z4-FAJG-2812



4MP 25x Starlight IR WizMind Network Dual-PTZ Camera for Traffic

> Dual PTZ system, dual vari-focal lens.

> 1/1.8″ 4Megapixel CMOS.

> Powerful 25x optical zoom.

> Starlight technology.

> Max. 25/30 fps@4M.

> H.265 encoding.

> IP67.

> Illegal parking detection and checkpoint capture.



DAHUA SD8A840FA-HNT 8MP 40x Starlight IR WizMind Network PTZ Camera for Traffic



SD8A840FA-HNT



8MP 40x Starlight IR WizMind Network PTZ Camera for Traffic

1/1.8″ 8Megapixel STARVIS™ CMOS.





>

Powerful 40x optical zoom.





>

Starlight technology.





>

Max. 25/30 fps@8MP.





>

H.265 encoding.





>

Illegal parking detection.





>

ANPR.





>

IP67.





>

2MP IR Mini-Bullet Network Camera





DAHUA IPC-B2B20-L-ZS



IPC-B2B20-L-ZS







2MP IR Mini-Bullet Network Camera





DAHUA IPC-B2B20-ZS



IPC-B2B20-ZS







4MP IR Mini-Bullet Network Camera





DAHUA IPC-B2B40-ZS



IPC-B2B40-ZS







2MP IR Mini-Dome Network Camera





DAHUA IPC-D2B20-L-ZS



IPC-D2B20-L-ZS







4MP IR Indoor Mini-Dome Network Camera





DAHUA IPC-D1B40



IPC-D1B40







4MP IR Mini-Dome Network Camera





DAHUA IPC-D2B40



IPC-D2B40







2MP IR Mini-Dome Network Camera





DAHUA IPC-D2B20-ZS



IPC-D2B20-ZS







4MP IR Mini-Dome Network Camera





DAHUA IPC-D2B40-ZS



IPC-D2B40-ZS







5MP Panoramic Network IR Fisheye Camera





DAHUA IPC-EW5531-AS



IPC-EW5531-AS







12MP Panoramic Network IR Fisheye Camera





DAHUA IPC-EBW81242



IPC-EBW81242



12MP Panoramic Network IR Fisheye Camera



> 12MP, 1/1.7”CMOS image sensor> Max output 12MP (4000×3000)@30fps> 3D DNR,AWB,HLC, BLC,ROI, SVC, SMART H.264/H.265> People counting in multiple areas, queuing management in multiple areas, heat map (number of peole /time), and track map> 2/2 Alarm in/out, 1/1 audio in/out> 12V DC/POE power support> IP67, IK10 protection





DAHUA IPC-EW5541-AS(OnlyForJordan) 5MP WizMind IR Fisheye Network CAMERA





DAHUA IPC-EW5541-AS(Only For Jordan)



IPC-EW5541-AS(Only For Jordan)



5MP WizMind IR Fisheye Network CAMERA



> 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 5MP (2592 × 1944) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in efficient IR illuminator, and the max. illumination distance: 10 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire, people counting in area

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 12V DC/PoE power supply, easy for installation

> Heat map for people counting. You can adjust the number of people, time threshold to generate a heat map, which can be exported.





1.3MP Dual-Lens People Counting AI Network Camera





DAHUA IPC-HD4140X-3D



IPC-HD4140X-3D







2MP IR Dome WI-FI Camera





DAHUA IPC-HDBW1235E-W-S2



IPC-HDBW1235E-W-S2



2MP IR Dome WI-FI Camera



> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Max. IR distance: 30 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Supports 256 G Micro SD card

> 12V DC power supply, easy for installation

> IP67, IK10 protection

> Supports Wi-Fi





4MP IR Dome WI-FI Camera





DAHUA IPC-HDBW1435E-W-S2



IPC-HDBW1435E-W-S2



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2560 × 1440) @20 fps

> H.265 codec, high compression rate, ultra-low bit rate · Max. IR distance: 30 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Supports 256 G Micro SD card

> 12V DC power supply, easy for installation

> IP67, IK10 protection

> Supports Wi-Fi





8MP WDR IR Dome Network Camera





DAHUA IPC-HDBW1831R-S



IPC-HDBW1831R-S







8MP WDR IR Dome Network Camera





DAHUA IPC-HDBW2831R-ZAS



IPC-HDBW2831R-ZAS







DAHUA IPC-HDBW2541E-S(OnlyForProject) 5MP IR Fixed-focal Dome WizSense Network Camera





DAHUA IPC-HDBW2541E-S(Only For Project)



IPC-HDBW2541E-S(Only For Project)



5MP IR Fixed-focal Dome WizSense Network Camera



* The parameters and datasheets below can only be applied to 2541-S2 series.

> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 40 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 protection.

> SMD Plus.





8MP WDR IR Dome Network Camera





DAHUA IPC-HDBW2831R-ZS



IPC-HDBW2831R-ZS







2MP IR Starlight Dome Network Camera





DAHUA IPC-HDBW3241E-Z



IPC-HDBW3241E-Z







2MP IR Starlight Dome Network Camera





DAHUA IPC-HDBW3241E-Z5



IPC-HDBW3241E-Z5







2MP WDR Full-color Starlight Dome Network Camera





DAHUA IPC-HDBW4239R-ASE



IPC-HDBW4239R-ASE







4MP IR mini Dome Network Camera





DAHUA IPC-HDBW4431E-ASE



IPC-HDBW4431E-ASE



4MP IR mini Dome Network Camera



> 1/3” 4Megapixel progressive scan CMOS> H.265&H.264 triple-stream encoding> 25/30fps@4M(2688×1520)> Smart Detection supported> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.8mm fixed lens (3.6mm, 6mm optional)> 1/1 Alarm in/out, 1/1 audio in/out> Max. IR LEDs Length 30m> Micro SD memory, IP67, IK10, PoE





2x2MP IR Mini Dome Network Camera





DAHUA IPC-HDBW4231F-E2-M/M12



IPC-HDBW4231F-E2-M/M12



2x2MP IR Mini Dome Network Camera



> Two 1/2.8” 2Megapixel progressive scan STARVISTM CMOS> H.265&H.264 dual-stream encoding> 25/30fps@2M(1920×1080)> Smart Detection supported> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.8mm fixed lens (3.6mm optional)> Max. IR LEDs Length 20m> Micro SD memory, IP67, IK10, PoE





2MP WDR IR Dome Network Camera





DAHUA IPC-HDBW5231E-ZE



IPC-HDBW5231E-ZE



2MP WDR IR Dome Network Camera



> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS> H.265&H.264 triple-stream encoding> 50/60fps@1080(1920×1080) > Smart Detection supported> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.7mm ~13.5mm motorized lens> 1/1 Alarm in/out, 1/1 audio in/out> Max. IR LEDs Length 50m> Micro SD memory, IP67, IK10, PoE+







2MP WDR IR Dome Network Camera





DAHUA IPC-HDBW5231R-ZE



IPC-HDBW5231R-ZE



2MP WDR IR Dome Network Camera



> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS> H.265&H.264 triple-stream encoding> 50/60fps@1080(1920×1080) > Smart Detection supported> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.7mm ~13.5mm motorized lens> 1/1 Alarm in/out, 1/1 audio in/out> Max. IR LEDs Length 50m> Micro SD memory, IP67, IK10, PoE





2MP Pro AI Full-color Fixed-focal Dome Network Camera





DAHUA IPC-HDBW5241R-ASE-NI



IPC-HDBW5241R-ASE-NI



2MP Pro AI Full-color Fixed-focal Dome Network Camera



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @30 fps

> H.265 codec, high compression rate, low bit rate

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human), abandoned object, missing object, loitering detection, people gathering, parking detection, heat map, and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 1 in, 1 out; Audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 12V DC/PoE power support

> ePoE for remote transmission

> IP67, IK10 protection





2MP Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5242H-Z6E-MF



IPC-HDBW5242H-Z6E-MF



2MP Vari-focal Dome WizMind Network Camera



> 2MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @60 fps

> Max. IR distance: 100 m

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 24V AC/PoE/12V DC power supply (power input ports vary depending on power supply)

> ePoE, IP67, IK10 protection

> Anti-corrosion coating (optional)

> Supports junction box mount

> SMD 3.0





2MP Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5242H-ZHE-MF



IPC-HDBW5242H-ZHE-MF



2MP Vari-focal Dome WizMind Network Camera



> 2MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @60 fps

> Max. IR distance: 50 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 24V AC/PoE/12V DC power supply (power input ports vary depending on power supply)

> ePoE, IP67, IK10 protection,Heater

> Anti-corrosion coating (optional)

> Supports junction box mount

> SMD 3.0





4 MP DHOP Vandal-proof IR Dome Network Camera





DAHUA IPC-HDBW5442E-ZE-OPAT



IPC-HDBW5442E-ZE-OPAT



4 MP DHOP Vandal-proof IR Dome Network Camera



> 4 MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 ×1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 50 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/24V AC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67/IK10 protection.





4MP WDR IR Dome Network Camera





DAHUA IPC-HDBW5431E-ZE



IPC-HDBW5431E-ZE



4MP WDR IR Dome Network Camera



> 1/3” 4Megapixel progressive scan CMOS> H.265&H.264 triple-stream encoding> 25/30fps@4Mp(2688×1520) > WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.7mm ~13.5mm motorized lens> Max. IR LEDs Length 50m> Micro SD card memory, IP67,IK10, PoE+





4MP Pro AI Full-color Fixed-focal Dome Network Camera





DAHUA IPC-HDBW5442R-ASE-NI



IPC-HDBW5442R-ASE-NI



4MP Pro AI Full-color Fixed-focal Dome Network Camera



> 1/1.8” 4Megapixel progressive scan CMOS

> H.265 & H.264 triple-stream encoding

> 25/30 fps@2688 × 1520, 50/60 fps@1080 (1920 × 1080)

> WDR (140 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 3.6 mm fixed lens

> 1/1 Alarm in/out, 1/1 audio in/out

> Micro SD memory, IP67, IK10







4MP Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5442H-Z4E



IPC-HDBW5442H-Z4E



4MP Vari-focal Dome WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520) @30 fps

> Max. IR distance: 80 m

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 24V AC/PoE/12V DC power supply (power input ports vary depending on power supply)

> ePoE, IP67, IK10 protection

> Anti-corrosion coating (optional)

> Supports junction box mount

> SMD 3.0





4MP Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5442H-ZHE



IPC-HDBW5442H-ZHE



4MP Vari-focal Dome WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520) @30 fps

> Max. IR distance: 40 m

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265,flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 24V AC/PoE/12V DC power supply (power input ports vary depending on power supply)

> ePoE, IP67, IK10 protection,Heater

> Anti-corrosion coating (optional)

> Supports junction box mount

> SMD 3.0





4MP Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5442H-ZE



IPC-HDBW5442H-ZE



4MP Vari-focal Dome WizMind Network Camera



> 4MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520) @30 fps

> Max. IR distance: 40 m

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265,flexible coding,applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 24V AC/PoE/12V DC power supply (power input ports vary depending on power supply)

> ePoE, IP67, IK10 protection

> Anti-corrosion coating (optional)

> Supports junction box mount

> SMD 3.0





5 MP DHOP Vandal-proof IR Dome Network Camera





DAHUA IPC-HDBW5541E-ZE-OPAT



IPC-HDBW5541E-ZE-OPAT



5 MP DHOP Vandal-proof IR Dome Network Camera



> 5 MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2592 × 1944)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 50 m.

> ROI, SMART H.264+/H.265+,flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/24V AC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67/IK10 protection.





4 MP DHOP IR-Bullet Box Network Camera





DAHUA IPC-HDBW5442R-ASE-OPAT



IPC-HDBW5442R-ASE-OPAT



4 MP DHOP IR-Bullet Box Network Camera



> 4 MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 ×1520)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67/IK10 protection.







5 MP DHOP IR-Bullet Box Network Camera





DAHUA IPC-HDBW5541R-ASE-OPAT



IPC-HDBW5541R-ASE-OPAT



5 MP DHOP IR-Bullet Box Network Camera



> 5 MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2592 × 1944)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67/IK10 protection.





8MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW5842H-Z4HE



IPC-HDBW5842H-Z4HE



8MP IR Dome WizMind Network Camera



> 8MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP(3840 × 2160) @25/30 fps

> H.264&H.265 coding, high compression ration

> WDR, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detection, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Three streams for two-channel HD video

> IP67, IK10 protection

> 12V DC power output, max. current 165mA , easy for installation





8 MP IR Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5842H-Z4HE-S2



IPC-HDBW5842H-Z4HE-S2



8 MP IR Vari-focal Dome WizMind Network Camera



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @30 fps.

> Max. IR distance: 80 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265,flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, power output; supports max. 256 G Micro SD card.

> 24 VAC/12 VDC/PoE power supply.

> ePoE: IP67, IK10 protection, Heater.

> SMD 3.0.

> Anti-corrosion model optional.





8MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW5842H-ZHE



IPC-HDBW5842H-ZHE



8MP IR Dome WizMind Network Camera



> 8MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Max outputs 8MP (3840×2160) @ 25 fps/30 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card, built-in ports, without cables

> 24V AC/12V DC/PoE power supply

> Three streams for two-channel HD video

> IP67, IK10 protection grade

> 12V DC power output, max. current 165mA , easy for installation





8 MP IR Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5842H-ZHE-S2



IPC-HDBW5842H-ZHE-S2



8 MP IR Vari-focal Dome WizMind Network Camera



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @30 fps.

> Max. IR distance: 40 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265,flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, power output; supports max. 256 G Micro SD card.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 24 VAC/12 VDC/PoE power supply.

> ePoE: IP67, IK10 protection, Heater.

> SMD 3.0.

> Anti-corrosion model optional.





8 MP IR Fixed-focal Dome WizMind Network Camera





DAHUA IPC-HDBW5842R-ASE-S2



IPC-HDBW5842R-ASE-S2



8 MP IR Fixed-focal Dome WizMind Network Camera



> 8 MP 1/1.8″ CMOS image sensor, low illuminance, high image definition (high definition image).

> Outputs max. 8 MP (3840× 2160) @30 fps.

> Max. IR distance: 50 m.

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; Supports max. 256 G Micro SD card, built-in Mic.

> 12 VDC/PoE power supply.

> ePoE, IP67, IK10 protection.

> SMD 3.0





12MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW71242H-Z



IPC-HDBW71242H-Z



12MP IR Dome WizMind Network Camera



> 12MP 1/1.7” CMOS image sensor, high image definition

> Outputs max. 12MP (4000 × 3000) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max. IR distance: 40 m

> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Perimeter Protection , Face Detection , Video Metadata , ANPR , People Counting , Queue Management

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply; 12V DC power output, max. current 165mA; easy for installation.

> IP67, IK10 protection

> Anti-corrosion coating (optional)

> Five streams for three-channel HD video







4MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW7442H-Z



IPC-HDBW7442H-Z



4MP IR Dome WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> 12V DC power output, max. current 165mA , easy for installation





4MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW7442H-Z4FR



IPC-HDBW7442H-Z4FR



4MP IR Dome WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recogni tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> 12V DC power output, max. current 165mA , easy for installation





4MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW7442H-Z4



IPC-HDBW7442H-Z4



4MP IR Dome WizMind Network Camera

> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





8MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW7842H-Z4



IPC-HDBW7842H-Z4



8MP IR Dome WizMind Network Camera



> 8MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP(3840 × 2160) @25/30 fps

> H.264&H.265 coding, high compression ration

> WDR, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detection, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





4MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW7442H-ZFR



IPC-HDBW7442H-ZFR



4MP IR Dome WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recogni tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> 12V DC power output, max. current 165mA , easy for installation





8MP IR Dome WizMind Network Camera





DAHUA IPC-HDBW7842H-Z



IPC-HDBW7842H-Z



8MP IR Dome WizMind Network Camera



> 8MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition> Max outputs 8MP (3840×2160) @25fps/30fps> H.264&H.265 coding, high compression ration · Wide dynamic, day/night,> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various> With deep learning algorithm, it supports people counting, face> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G> 24V AC/PoE/12V DC power support> Five streams for three-channel HD video> IP67, IK10 protection grade> Anti-corrosion coating (optional)> 12V DC power output, max. current 165mA , easy for installation







2MP IR AI Dome Network Camera





DAHUA IPC-HDBW8241E-Z



IPC-HDBW8241E-Z







2MP IR Starlight Dome Network Camera





DAHUA IPC-HDBW8242E-Z4FD



IPC-HDBW8242E-Z4FD







4MP IR Dome WizMind Network Camera (Special model for Mongolian market )





DAHUA IPC-HDBW9442H-ZFR-MN



IPC-HDBW9442H-ZFR-MN



4MP IR Dome WizMind Network Camera (Special model for Mongolian market )



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration · Wide dynamic, day/night,3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recogni tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation







8MP IR Dome WizMind Network Camera (Special model for Mongolian market )





DAHUA IPC-HDBW9842H-Z-MN



IPC-HDBW9842H-Z-MN



8MP IR Dome WizMind Network Camera (Special model for Mongolian market )



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 8MP (3840×2160) @25fps/30fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night,3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recogni tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





2MP IR AI Dome Network Camera





DAHUA IPC-HDBW8241E-Z5

IPC-HDBW8241E-Z5







2MP IR AI Dome Network Camera

> 1/2.8” 2Megapixel progressive scan CMOS

> H.265&H.264 triple-stream encoding

> 50/60fps@1080P(1920×1080)

> WDR(140dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC

> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

> 7mm ~35mm motorized lens

> Micro SD memory, PoE+

> Max. IR LEDs Length 100m





4MP IR Dome WizMind Network Camera (Special model for Mongolian market )





DAHUA IPC-HDBW9442H-Z-MN



IPC-HDBW9442H-Z-MN



4MP IR Dome WizMind Network Camera (Special model for Mongolian market )



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264/H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





2MP IR Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDPW5242G-ZE-MF



IPC-HDPW5242G-ZE-MF



2MP IR Vari-focal Dome WizMind Network Camera



> 1/1.8″ 2Megapixel progressive scan CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 50/60 fps@1080P(1920 × 1080)

> WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC· Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.7 mm–12.0 mm motorized lens

> 1/1 Alarm in/out, 1/1 audio in/out

> Max. IR LEDs Length 40 m

> Micro SD memory







2MP Pro AI IR Vari-focal Dome Network Camera





DAHUA IPC-HDPW5241G-Z



IPC-HDPW5241G-Z







2MP Pro AI IR Vari-focal Dome Network Camera





DAHUA IPC-HDPW5242G-Z-MF



IPC-HDPW5242G-Z-MF







4MP IR Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDPW5442G-ZE



IPC-HDPW5442G-ZE



4MP IR Vari-focal Dome WizMind Network Camera



> 1/1.8″ 4Megapixel progressive scan CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 25/30 fps@2688 × 1520, 50/60 fps@1080P (1920 × 1080)

> WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.7 mm–12.0 mm motorized lens

> 1/1 Alarm in/out, 1/1 audio in/out

> Max. IR LEDs Length 40 m

> Micro SD memory







2MP IR Vari-focal Dome WizMind Network Camera





DAHUA IPC-HDPW5241G-ZE



IPC-HDPW5241G-ZE



2MP IR Vari-focal Dome WizMind Network Camera



> 1/2.8″ 2Megapixel progressive scan STARVIS™ CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 25/30 fps@1080P (1920 × 1080)

> WDR (120 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.7 mm–13.5 mm motorized lens

> 1/1 Alarm in/out, 1/1 audio in/out

> Max. IR LEDs Length 40 m

> Micro SD memory





5MP Pro AI IR Vari-focal Network Camera





DAHUA IPC-HDPW5541G-Z



IPC-HDPW5541G-Z







4MP Pro AI IR Vari-focal Dome Network Camera





DAHUA IPC-HDPW5442G-Z



IPC-HDPW5442G-Z







5MP IR Vari-focal WizMind Network Camera





DAHUA IPC-HDPW5541G-ZE



IPC-HDPW5541G-ZE



5MP IR Vari-focal WizMind Network Camera



> 1/2.7” 5Megapixel progressive scan CMOS.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Outputs max. 5MP (2592 × 1944)@20 fps , and supports 4MP (2688 × 1520)@25/30 fps.

> 20 fps@2592 × 1944, 50/60 fps@1080P (1920 × 1080).

> WDR (120 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC.

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS.

> 2.7 mm–13.5 mm motorized lens.

> 1/1 Alarm in/out, 1/1 audio in/out.

> Max. IR LEDs Length 40 m.

> Micro SD memory.







DAHUA IPC-HDW1431T1-S4(OnlyForJordan) 4MP Entry IR Fixed-focal Eyeball Netwok Camera





DAHUA IPC-HDW1431T1-S4(Only For Jordan)



IPC-HDW1431T1-S4(Only For Jordan)



4MP Entry IR Fixed-focal Eyeball Netwok Camera



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs 4MP (2560 × 1440) @25/30 fps, and supports max. 4MP (2688 × 1520) @20 fps

> H.265 codec, high compression rate, ultra-low bit rate> Built-in IR LED, max. IR distance: 30 m> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments > Image Rotation, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes > Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access, voltage detection> 12V DC/PoE power support > IP67, protection





2MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HDW2249TM-S-IL



IPC-HDW2249TM-S-IL



> Outputs max. 2 MP (1920 × 1080)@25/30 fps.> H.265 codec, high compression rate, ultra-low bit rate.> Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).> Supports max. 256 G Micro SD card; built in MIC.> 12 VDC/PoE power supply, easy for installation.> IP67 protection.> SMD Plus.





DAHUA IPC-HDW2431T-S2(OnlyForJordan) 4MP Lite IR Fixed-focal Eyeball Network Camera





DAHUA IPC-HDW2431T-S2(Only For Jordan)



IPC-HDW2431T-S2(Only For Jordan)



4MP Lite IR Fixed-focal Eyeball Network Camera



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs 4MP (2560 × 1440)@25/30 fps, Max. supports 4MP (2688 × 1520) @ 20 fps

> H.265 coding, high compression ration, low bit rate

> Built-in IR LED, max IR distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering,no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection

> Max. 256 GB SD card

> 12V DC/POE power supply

> IP67 protection







4MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HDW2449TM-S-IL



IPC-HDW2449TM-S-IL



> Outputs max. 4 MP (2688 × 1520)@20 fps, and supports 2560 × 1440 @25/30 fps.> H.265 codec, high compression rate, ultra-low bit rate.> Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).> Supports max. 256 G Micro SD card; built in MIC.> 12 VDC/PoE power supply, easy for installation.> IP67 protection.> SMD Plus.





5MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HDW2549TM-S-IL



IPC-HDW2549TM-S-IL



5MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD Plus.





5MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HDW2549T-S-IL



IPC-HDW2549T-S-IL



5MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD Plus.





8MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HDW2849TM-S-IL



IPC-HDW2849TM-S-IL



8MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera



> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 × 1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD Plus.





8MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HDW2849T-S-IL



IPC-HDW2849T-S-IL



8MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera



> 8-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD Plus





5MP Full-color Active Deterrence Fixed-focal Eyeball WizSense Network Camera





DAHUA IPC-HDW3549H-AS-PV



IPC-HDW3549H-AS-PV



5MP Full-color Active Deterrence Fixed-focal Eyeball WizSense Network Camera



> 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 5MP (2592 × 1944) @20 fps, and supports 4MP (2688 × 1520) @25/30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in warm illuminator, and the max. illumination distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing.

> Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and spearker

> 12V DC/PoE power supply

> IP67 protection

> SMD Plus

> Red and blue flashlight alarm





8MP Full-color Active Deterrence Fixed-focal Eyeball WizSense Network Camera





DAHUA IPC-HDW3849H-AS-PV



IPC-HDW3849H-AS-PV



> 8MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max.8MP (3840 × 2160) @20 fps (AI function enabled by default)and supports 8MP (3840 × 2160) @25/30 fps (when AI function disabled)

> H.265 codec, high compression rate, low bit rate

> Built-in warm illuminator, and the max. illumination distance: 30 m

> ROI, Smart H.265+/Smart H.264+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital

> watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and · accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection

> Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing

> Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker

> 12V DC/PoE power supply

> IP67 protection

> SMD Plus

> Red and blue flashlight alarm



6MP IR Eyeball Network Camera





DAHUA IPC-HDW4631EM-ASE



IPC-HDW4631EM-ASE



6MP IR Eyeball Network Camera



> 1/2.9” 6Megapixel progressive scan STARVIS™ CMOS> H.265&H.264 triple-stream encoding> 20fps@6MP(3072×2048), 25/30fps@4MP(2688×1520)> Smart detection supported> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.8mm fixed lens (3.6mm optional)> Built-in Mic> Max. IR LEDs Length 50m> Micro SD memory, IP67, PoE





2MP IR Fixed-focal Eyeball WizMind Network Camera





DAHUA IPC-HDW5241H-AS-PV



IPC-HDW5241H-AS-PV



2MP IR Fixed-focal Eyeball WizMind Network Camera



> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

>Outputs max. 2 MP (1920 × 1080)@30 fps.

>H.265 codec, high compression rate, ultra-low bit rate.

>Built-in IR LED, and the max. illumination distance is 50 m.

>ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

>Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

>Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection and heat map.

>Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

>Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

>Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC and speaker, support two-way talk.

>12 VDC/PoE power supply, easy for installation.

>IP67 protection.

>SMD 3.0.





2MP WDR IR Eyeball AI Network Camera





DAHUA IPC-HDW5241TM-AS



IPC-HDW5241TM-AS







4MP WDR IR Eyeball AI Network Camera





DAHUA IPC-HDW5442TM-AS



IPC-HDW5442TM-AS







2MP WDR Eyeball WizMind Network Camera





DAHUA IPC-HDW5241TM-AS-LED



IPC-HDW5241TM-AS-LED



2MP WDR Eyeball WizMind Network Camera



> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 25/30 fps@1080P (1920 × 1080)

> WDR (120 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.8 mm fixed lens (3.6 mm, 6.0 mm optional)

> Built-in MIC

> Max. LEDs Length 20 m

> Micro SD memory, IP67





4MP WDR Eyeball AI Network Camera





DAHUA IPC-HDW5442TM-AS-LED



IPC-HDW5442TM-AS-LED



4MP WDR Eyeball AI Network Camera



> 1/1.8” 4Megapixel progressive scan CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 25/30 fps@2688 × 1520, 50/60 fps@1080P (1920 × 1080)

> WDR (140 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.8 mm fixed lens (3.6 mm, 6.0 mm optional)

> Built-in MIC· Max. LEDs Length 20 m

> Micro SD memory, IP67





5MP IR Fixed-focal Eyeball WizMind Network Camera





DAHUA IPC-HDW5541H-AS-PV



IPC-HDW5541H-AS-PV



5MP IR Fixed-focal Eyeball WizMind Network Camera



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2592 × 1944)@20 fps , and supports 4MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection and heat map.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC and speaker, support two-way talk.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD 3.0







5MP WDR IR Eyeball AI Network Camera





DAHUA IPC-HDW5541TM-AS



IPC-HDW5541TM-AS







2MP Starlight box Network Camera





DAHUA IPC-HF3241F



IPC-HF3241F







2 MP Box WizMind Network Camera





DAHUA IPC-HF5241E-E



IPC-HF5241E-E



> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2 MP (1920 × 1080) @30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection, heat map and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; 485; BNC; supports max. 256 G Micro SD card, built in MIC.

> 24 VAC/12 VDC/PoE power supply, easy for installation.

> ePoE.

> SMD 3.0









3MP WizMind Dual-Lens Network Camera





DAHUA IPC-HDW8341X-3D-S2



IPC-HDW8341X-3D-S2



3MP WizMind Dual-Lens Network Camera



> 3MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 3MP (2048 × 1536) @30 fps

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> People counting: Queue management, people counting in area, entry/ exit number counting, and it can output daily/monthly/yearly report

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G

> Micro SD card, built-in Mic and speaker. Siren active deterrence, built- in 8 voices, and user can import custom voices.

> 12V DC/PoE power supply

> IP67, IK10 protection





2MP Box WizMind Network Camera





DAHUA IPC-HF5242E-E-MF



IPC-HF5242E-E-MF



2MP Box WizMind Network Camera



> 1/1.8″ 2Megapixel progressive scan CMOS

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, appli cable to various bandwidth and storage environments

> 50/60 fps@1080 (1920 × 1080)

> WDR (140 dB), Day/Night (ICR), 3D NR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2/1 Alarm in/out, 1/1 audio in/out (Built-in MIC)

> Auto back focus(ABF)

> Micro SD memory

> SMD3.0







5 MP Box WizMind Network Camera





DAHUA IPC-HF5541E-E



IPC-HF5541E-E



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2592 × 1944)@20 fps , and supports 4MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection, heat map and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; 485; BNC; supports max. 256 G Micro SD card, built in MIC.

> 24 VAC/12 VDC/PoE power supply, easy for installation.

> ePoE.

> SMD 3.0









4MP WDR Box Network Camera





DAHUA IPC-HF5431E-E



IPC-HF5431E-E



> H.264&H.265 Triple-stream encoding> 25/30fps@4M(2688×1520) > Smart Detection supported> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2/1 Alarm in/out, 1/1 audio in/out(Built-in Mic)> Auto back focus(ABF)> Micro SD memory, PoE





4 MP Box WizMind Network Camera





DAHUA IPC-HF5442E-E



IPC-HF5442E-E



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection, heat map and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 2 in, 1 out; audio: 1 in, 1 out; 485; BNC; supports max. 256 G Micro SD card, built in MIC.

> 24 VAC/12 VDC/PoE power supply, easy for installation.

> ePoE.

> SMD 3.0





8 MP Box WizMind Network Camera





DAHUA IPC-HF5842F-ZE-S2



IPC-HF5842F-ZE-S2



> Outputs max. 8 MP (3840× 2160) @30 fps.> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments. > Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 256 G Micro SD card, built-in Mic.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 24 VAC/12 VDC/PoE power supply.> ePoE> SMD 3.0





12MP Box WizMind Network Camera





DAHUA IPC-HF71242F



IPC-HF71242F



> 12MP 1/1.7” CMOS image sensor, high image definition

> Outputs max. 12MP (4000 × 3000) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Perimeter Protection , Face Detection , Video Metadata , ANPR , People Counting , Queue Management

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply; 12V DC power output, max. current 165mA; easy for installation.

> Five streams for three-channel HD video





8MP BOX WizMind Network Camera





DAHUA IPC-HF7842F



IPC-HF7842F



> 8MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 8MP (3840×2160) @25fps/30fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> 12V DC power output, max. current 165mA , easy for installation





4MP BOX WizMind Network Camera





DAHUA IPC-HF7442F



IPC-HF7442F



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> 12V DC power output, max. current 165mA , easy for installation





4MP BOX WizMind Network Camera





DAHUA IPC-HF7442F-FR



IPC-HF7442F-FR



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recognition, perimeter protection etc

> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/PoE/12V DC power support

> Five streams for three-channel HD video

> 12V DC power output, max. current 165mA , easy for installation





12MP Box Network Camera





DAHUA IPC-HF81230E-E



IPC-HF81230E-E







2MP Starlight Box Network Camera





DAHUA IPC-HF8232F-E



IPC-HF8232F-E







2MP AI Box Network Camera





DAHUA IPC-HF8241F



IPC-HF8241F







2MP WDR Box Network Camera





DAHUA IPC-HF8231F-E



IPC-HF8231F-E







3MP WDR Box Network Camera





DAHUA IPC-HF8331F-E



IPC-HF8331F-E







2MP Starlight Face Recognition Box AI Network Camera





DAHUA IPC-HF8242F-FR



IPC-HF8242F-FR







6MP Box Network Camera





DAHUA IPC-HF8630F-E



IPC-HF8630F-E







2MP Starlight Face Detection Box AI Network Camera





DAHUA IPC-HF8242F-FD



IPC-HF8242F-FD







4MP Polar Light Bullet WizMind Network Camera





DAHUA IPC-HFS7443-Z-LI-D2



IPC-HFS7443-Z-LI-D2



4MP Polar Light Bullet WizMind Network Camera



> Built-in GPU chip and deep learning algorithm, improve detection accuracy

> Five intelligent resources switchable: Video metadata, face recognition, face detection

> Two 4MP, 1/1.8” CMOS image sensors, one is for collecting black and white information, and the other is for collecting colorful information, and the camera will integrate the collected information

> With multi-spectrum fusion technology, the camera can guarantee the clarity of the image and color rendition in the environment of ultra-low illuminance; and it can provide colorful image with IR LED on

> Outputs max. 4MP (2688 × 1520) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in illuminator of dual light fusion, and the max. illumination distance is 150 m

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Alarm: 3 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card

> 12V DC power supply; 12V DC power output, and max. current 165mA; easy for installation

> P-Iris





8MP 5G Bullet WizMind Network Camera





DAHUA IPC-HFS7842-Z-5G-LED



IPC-HFS7842-Z-5G-LED



8MP 5G Bullet WizMind Network Camera



> 8MP 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (3840 × 2160) @25/30 fps · H.265 codec, high compression rate, ultra-low bit rate

> Built-in efficient warm light, max. illumination distance: 80 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking

> With deep learning algorithm, it supports people counting, face detection,perimeter protection, video metadata etc

> Alarm: 7 in, 3 out; audio: 2 in, 1 out; 485; BNC; supports max. 256 G SD card

> 12V DC power supply; easy for installation

> IP67 protection

> GPS/BDS

> Support 5G module (N41, N78, and N79 frequency range), and NSA and SA network





DAHUA IPC-HFW1230S1-S5(OnlyForJordan) 2MP Entry IR Fixed-Focal Bullet Netwok Camera





DAHUA IPC-HFW1230S1-S5(Only For Jordan)



IPC-HFW1230S1-S5(Only For Jordan)



2MP Entry IR Fixed-Focal Bullet Netwok Camera



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition> Outputs max. 2MP (1920 × 1080) @25/30 fps> H.265 codec, high compression rate, ultra-low bit rate> Built-in efficient IR illuminator, and the max. illumination distance is 30 m> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking,applicable to various monitoring scenes > Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access> 12V DC/PoE power supply> IP67 protection





DAHUA IPC-HFW1431T1-ZS-S4(OnlyForJordan) 4MP Entry IR Vari-focal Bullet Netwok Camera





DAHUA IPC-HFW1431T1-ZS-S4(Only For Jordan)



IPC-HFW1431T1-ZS-S4(Only For Jordan)



4MP Entry IR Vari-focal Bullet Netwok Camera



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs 4MP (2560 × 1440) @25/30 fps, and supports max. 4MP (2688 × 1520) @20 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max. IR distance: 35 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Image Rotation, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes > Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Supports max. 256 GB SD card

> 12V DC/PoE power support

> IP67 protection





4MP IR Bullet WI-FI Camera





DAHUA IPC-HFW1435S-W-S2



IPC-HFW1435S-W-S2



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2560 × 1440) @20 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Max. IR distance: 30 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Supports 256 G Micro SD card

> 12V DC power supply, easy for installation

> IP67 protection

> Supports Wi-Fi





2MP IR Bullet WI-FI Camera





DAHUA IPC-HFW1235S-W-S2



IPC-HFW1235S-W-S2



> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Max. IR distance: 30 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Supports 256 G Micro SD card

> 12V DC power supply, easy for installation

> IP67 protection

> Supports Wi-Fi





8MP Entry IR Fixed-focal Bullet Network Camera





DAHUA IPC-HFW1830S-S6



IPC-HFW1830S-S6



> Outputs max. 8MP (3840 × 2160) @15 fps and supports 2688 × 1520 (2688 × 1520) @25/30 fps> H.265 codec, high compression rate, and ultra-low bit rate.> Built-in IR LED, and the max. illumination distance is 30 m.> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments. > Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking,applicable to various monitoring scenes. > Abnormality detection: Motion detection, video tampering, audio detection, network disconnection, IP conflict, and illegal access.> Built-in MIC.> 12 V DC/PoE power supply.> IP67 protection.





5MP Entry IR Fixed-focal Bullet Network Camera





DAHUA IPC-HFW1530S-S6



IPC-HFW1530S-S6



> Outputs max. 5MP (2880 × 1620) @20 fps and supports 2688 × 1520 (2688 × 1520) @25/30 fps.> H.265 codec, high compression rate, and ultra-low bit rate.> Built-in IR LED, and the max. illumination distance is 30 m.> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, > Abnormality detection: Motion detection, video tampering, audio detection, network disconnection, IP conflict, and illegal access.> Built-in MIC.> 12 V DC/PoE power supply.> IP67 protection.





2MP Lite Full-color Fixed-focal Bullet Network Camera





DAHUA IPC-HFW2230M-AS-LED



IPC-HFW2230M-AS-LED



2MP Lite Full-color Fixed-focal Bullet Network Camera



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs 2MP (1920 × 1080)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in LEDs, max LED distance: 20 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Abnormality detection: Motion detection, video tampering, scene changing, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 128 GB Micro SD card

> 12V DC/PoE power support; 12V DC power output, max. current 165mA

> IP67 protection





2MP Lite Full-color Fixed-focal Bullet Network Camera





DAHUA IPC-HFW2230M-AS-LED-B



IPC-HFW2230M-AS-LED-B



2MP Lite Full-color Fixed-focal Bullet Network Camera



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs 2MP (1920 × 1080)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in LEDs, max LED distance: 25 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Abnormality detection: Motion detection, video tampering, scene changing, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 128 GB Micro SD card

> 12V DC/PoE power support; 12V DC power output, max. current 165mA

> IP67 protection





8MP WDR IR Mini Bullet Network Camera





DAHUA IPC-HFW1831E



IPC-HFW1831E







8MP WDR IR Mini Bullet Network Camera





DAHUA IPC-HFW1831C-PIR



IPC-HFW1831C-PIR







2MP Smart Dual Illumination Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW2249T-AS-IL



IPC-HFW2249T-AS-IL



2MP Smart Dual Illumination Fixed-focal Bullet WizSense Network Camera



> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2 MP (1920 × 1080)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED, the max. IR light distance is 60 m and max. warm light is 50 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 (optional) protection.

> SMD Plus.





4MP WDR IR Bullet Network Camera





DAHUA IPC-HFW2431T-ZS/VFS



IPC-HFW2431T-ZS/VFS







4MP Smart Dual Illumination Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW2449T-AS-IL



IPC-HFW2449T-AS-IL



4MP Smart Dual Illumination Fixed-focal Bullet WizSense Network Camera



> 4-MP 1/2.9″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@20 fps, and supports 2560 × 1440 @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED, the max. IR light distance is 60 m and max. warm light is 50 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 (optional) protection.

> SMD Plus.





5MP WDR IR Bullet Network Camera





DAHUA IPC-HFW2531T-ZS/VFS



IPC-HFW2531T-ZS/VFS







DAHUA IPC-HFW2541T-ZS(I)(A)(OnlyForProject) 5MP IR Vari-focal Bullet WizSense Network Camera





DAHUA IPC-HFW2541T-ZS(I)(A)(Only For Project)



IPC-HFW2541T-ZS(I)(A)(Only For Project)



5MP IR Vari-focal Bullet WizSense Network Camera



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.> Outputs max. 5 MP (2592 × 1944) @20 fps, and supports 4 MP (2688 × 1520) @25/30 fps.> H.265 codec, high compression rate, ultra-low bit rate.> Built-in IR LED, and the max. illumination distance is 60 m.> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.> Intelligent monitoring: Intrusion and tripwire (the two functions support the classification and accurate detection of vehicle and human).> Abnormality detection: Motion detection, video tampering, scene changing, audio detection (Only – ZAS supports) , no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports). > supports max. 256 G Micro SD card.> 12 VDC/PoE power supply, easy for installation.> IP67 protection.> SMD Plus.





8MP WDR IR Bullet Network Camera





DAHUA IPC-HFW2831T-ZAS



IPC-HFW2831T-ZAS







8MP WDR IR Bullet Network Camera





DAHUA IPC-HFW2831T-ZS



IPC-HFW2831T-ZS







2MP IR Starlight Bullet Network Camera





DAHUA IPC-HFW3241E-Z



IPC-HFW3241E-Z







2MP IR Fixed focal Bullet WizSense 4G Network Camera





DAHUA IPC-HFW3241DF-AS-4G



IPC-HFW3241DF-AS-4G



> Outputs max. 2MP (1920 × 1080)@25/30 fps.> H.265 codec, high compression rate, ultra-low bit rate.> Built-in IR LED, and the max. illumination distance is 50 m.> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments. > Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. > Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human). > Abnormality detection: Motion detection, privacy masking, no SD card, SD card full, SD card error, network disconnection, IP conflict, and illegal access > Support low power push alarm function; support the intergration of solar energy. > Support the camera to get the power information through 485 link, and OSD overlay display. > Alarm: 2 in,2 out; audio: 1 in, 1 out; 1 RS-485; supports max. 256 G Micro SD card. > 12 VDC power supply.> IP67 protection.> SMD 3.0.





2MP IR Starlight Bullet Network Camera





DAHUA IPC-HFW3241E-Z5



IPC-HFW3241E-Z5







2MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3249T1-AS-PV



IPC-HFW3249T1-AS-PV



2MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in warm illuminator, and the max. illumination distance: 40 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing.

> Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker

> 12V DC/PoE power supply

> IP67 protection

> SMD Plus

> Red and blue flashlight alarm





4MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3449T1-AS-PV



IPC-HFW3449T1-AS-PV



4MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera



> 4MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520) @30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in warm illuminator, and the max. illumination distance: 40 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing.

> Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker

> 12V DC/PoE power supply

> IP67 protection

> SMD Plus

> Red and blue flashlight alarm







4MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3449T1-AS-PV-S3



IPC-HFW3449T1-AS-PV-S3



> 4MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 3.0.

> One-click arming/disarming through alarm input.



DAHUA IPC-HFW3541E-S-S2(OnlyforProject) 5 MP IR Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3541E-S-S2(Only for Project)

IPC-HFW3541E-S-S2(Only for Project)



5 MP IR Fixed-focal Bullet WizSense Network Camera

> 5-MP 1/2.7″ CMOS image sensor, excellent low luminance performance and high definition of images.

> Outputs max. 5 MP (2960 × 1668) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, max. IR distance: 50 m.

> ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – AS supports); audio: 1 in, 1 out (Only – AS supports); max. 256 G Micro SD card. built-in Mic.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD 4.0, AI SSA.





5MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3549T1-AS-PV



IPC-HFW3549T1-AS-PV



5MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera



> 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 5MP (2592 × 1944) @20 fps, and supports 4MP (2688 × 1520) @25/30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in warm illuminator, and the max. illumination distance: 40 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing.

> Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker

> 12V DC/PoE power supply

> IP67 protection

> SMD Plus

> Red and blue flashlight alarm





5MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3549T1-AS-PV-S3



IPC-HFW3549T1-AS-PV-S3



5MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2592 × 1944)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,

> network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 3.0.

> One-click arming/disarming through alarm input.





8MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3849T1-AS-PV



IPC-HFW3849T1-AS-PV



8MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera



> 8MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (3840 × 2160) @20 fps (AI function enabled by default)and supports 8MP (3840 × 2160) @25/30 fps (with AI function disabled)

> H.265 codec, high compression rate, low bit rate

> Built-in warm illuminator, and the max. illumination distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various band width and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Tripwire, intrusion (the three functions support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, net work disconnection, IP conflict, illegal access, and voltage detection

> Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing

> Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker

> 12V DC/PoE power supply

> IP67 protection

> SMD Plus

> Red and blue flashlight alarm





8MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3849T1-AS-PV-S3



IPC-HFW3849T1-AS-PV-S3



8MP Smart Dual Illumination Active Deterrence Fixed-focal Bullet WizSense Network Camera



> 8MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; buit-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 3.0.

> One-click arming/disarming through alarm input.





2MP 4G IR Bullet Network Camera





DAHUA IPC-HFW4230M-4G-AS-I2



IPC-HFW4230M-4G-AS-I2



2MP 4G IR Bullet Network Camera



> 1/2.9” 2Megapixel progressive CMOS

> H.265&H.264 dual-stream encoding

> 25/30fps@2M(1920×1080)

> Day/Night(ICR), 3DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS(DSS/PSS) &DMSS

> Micro SD card slot, up to 256GB

> 3.6mm,6mm fixed lens

> Max. IR LEDs Length 40m

> 4G supported ·

> IP67





2MP WDR IR Bullet Network Camera





DAHUA IPC-HFW5231E-Z12E



IPC-HFW5231E-Z12E



2MP WDR IR Bullet Network Camera



> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS> H.265&H.264 triple-stream encoding> 50/60fps@1080(1920×1080) > Smart Detection supported> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 5.3mm ~64mm 12x zoom lens> 2/1 Alarm in/out, 1/1 audio in/out> Max. IR LEDs Length 200m> Micro SD memory, IP67, IK10, PoE





2MP WDR Full-color Starlight Mini Bullet Network Camera





DAHUA IPC-HFW4239T-ASE



IPC-HFW4239T-ASE







2MP IR Fixed-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5241E-SE



IPC-HFW5241E-SE



> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2 MP (1920 × 1080)@30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection, heat map and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> ePoE; IP67 protection.

> SMD 3.0





2MP Pro AI IR Fixed-focal Bullet Network Camera





DAHUA IPC-HFW5241E-S



IPC-HFW5241E-S













2MP WDR Bullet WizMind Network Camera





DAHUA IPC-HFW5241T-AS-LED



IPC-HFW5241T-AS-LED



2MP WDR Bullet WizMind Network Camera



> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 25/30 fps@1080P (1920 × 1080)

> WDR (120 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.8 mm fixed lens (3.6 mm, 6.0 mm, 8.0 mm optional)

> 1/1 Alarm in/out, 1/1 audio in/out

> Max. LEDs Length 25 m

> Micro SD memory, IP67,IK10







2MP Pro AI IR Bullet Network Camera





DAHUA IPC-HFW5241T-S



IPC-HFW5241T-S







4MP Pro AI IR Fixed-focal Bullet Network Camera





DAHUA IPC-HFW5442E-S



IPC-HFW5442E-S







4MP IR Fixed-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5442E-SE



IPC-HFW5442E-SE



4MP IR Fixed-focal Bullet WizMind Network Camera



> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520)@30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection, heat map and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> ePoE; IP67 protection.

> SMD 3.0







4MP Vari-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5442H-ZE



IPC-HFW5442H-ZE



4MP Vari-focal Bullet WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520) @30 fps

> Max. IR distance: 60 m

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265,AI H.264/H.265, flexible coding, applicable to various bandwidth and storageenvironments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card

> 12V DC/PoE power supply

> ePoE, IP67, IK10 protection

> Anti-corrosion coating (optional)

> Supports junction box mount

> SMD 3.0





4 MP DHOP Vandal-proof IR Dome Network Camera





DAHUA IPC-HFW5442E-ZE-OPAT



IPC-HFW5442E-ZE-OPAT



4 MP DHOP Vandal-proof IR Dome Network Camera



> 4 MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 ×1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 60 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67 protection.





4MP Pro AI Full-color Fixed-focal Bullet Network Camera





DAHUA IPC-HFW5442T-ASE-NI



IPC-HFW5442T-ASE-NI



4MP Pro AI Full-color Fixed-focal Bullet Network Camera



> 1/1.8” 4Megapixel progressive scan CMOS

> H.265 & H.264 triple-stream encoding

> 25/30 fps@2688 × 1520, 50/60 fps@1080 (1920 × 1080)

> WDR (140 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 3.6 mm fixed lens

> 1/1 Alarm in/out, 1/1 audio in/out

> Micro SD memory, IP67





4 MP DHOP IR-Bullet Box Camera Network CAMERA





DAHUA IPC-HFW5442T-ASE-OPAT



IPC-HFW5442T-ASE-OPAT



4 MP DHOP IR-Bullet Box Camera Network CAMERA



> 4 MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 ×1520)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67 protection.





4MP WDR Bullet WizMind Network Camera





DAHUA IPC-HFW5442T-AS-LED



IPC-HFW5442T-AS-LED



4MP WDR Bullet WizMind Network Camera



> 1/1.8” 4Megapixel progressive scan CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> 25/30 fps@2688 × 1520, 50/60 fps@1080P (1920 × 1080)

> WDR (140 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.8 mm fixed lens (3.6 mm, 6.0 mm optional)

> 1/1 Alarm in/out, 1/1 audio in/out

> Max. LEDs Length 20 m

> Micro SD memory, IP67,IK10





4MP Pro AI IR Bullet Network Camera





DAHUA IPC-HFW5442T-S



IPC-HFW5442T-S







5MP IR Fixed-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5541E-SE



IPC-HFW5541E-SE



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2592 × 1944)@20 fps , and supports 4MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 50 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection, heat map and face detection.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, easy for installation.

> ePoE; IP67 protection.

> SMD 3.0







5MP Pro AI IR Fixed-focal Bullet Network Camera





DAHUA IPC-HFW5541E-S



IPC-HFW5541E-S







DAHUA IPC-HFW5541E-ZE(forUruguay) 5MP IR Vari-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5541E-ZE(for Uruguay)



IPC-HFW5541E-ZE(for Uruguay)



5MP IR Vari-focal Bullet WizMind Network Camera



> 1/2.7” 5Megapixel progressive scan CMOS

> ROI, SMART H.264+/H.265+, flexible coding, applicable to variousbandwidth and storage environments

> 25 fps@2592 × 1944, 50/60 fps@1080P(1920 × 1080)

> WDR (130 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC

> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS

> 2.7 mm–13.5 mm motorized lens

> 2/1 Alarm in/out, 1/1 audio in/out

> Max. IR LEDs Length 50 m

> Micro SD memory, IP67, IK10





5 MP DHOP Vandal-proof IR Dome Network Camera





DAHUA IPC-HFW5541E-ZE-OPAT



IPC-HFW5541E-ZE-OPAT



5 MP DHOP Vandal-proof IR Dome Network Camera



> 5 MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2592 × 1944)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 60 m.

> ROI, SMART H.264+/H.265+,flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67 protection.





5 MP DHOP IR-Bullet Box Network Camera





DAHUA IPC-HFW5541T-ASE-OPAT



IPC-HFW5541T-ASE-OPAT



5 MP DHOP IR-Bullet Box Network Camera



> 5 MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5 MP (2592 × 1944)@20 fps and supports 4 MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED; the max. IR illumination distance is 30 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, appli cable to various monitoring scenes.

> Abnormality detection: motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error,network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card.

> 12 VDC/PoE power supply, ePoE, transmission over long distance, easy for installations of various scenes.

> IP67 protection.





5MP IR Fixed-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5541T-AS-PV



IPC-HFW5541T-AS-PV



5MP IR Fixed-focal Bullet WizMind Network Camera



> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 5MP (2592 × 1944)@20 fps , and supports 4MP (2688 × 1520)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SMART H.264 +/H.265+,AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); abandoned object, missing object, loitering detection, people gathering, parking detection and heat map.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Sound and light alarm linkage. When the alarm is triggered, the sound and light will be linked.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in speaker.

> 12 VDC/PoE power supply, easy for installation.

> IP67 and IK10 protection.

> SMD 3.0.





5MP Pro AI IR Bullet Network Camera





DAHUA IPC-HFW5541T-S



IPC-HFW5541T-S







8MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW5842H-Z4HE



IPC-HFW5842H-Z4HE



8MP IR Bullet WizMind Network Camera



> 8MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP(3840 × 2160) @25/30 fps

> H.264&H.265 coding, high compression ration

> WDR, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detection, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Three streams for two-channel HD video

> IP67, IK10 protection

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





8 MP IR Vari-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5842H-Z4HE-S2



IPC-HFW5842H-Z4HE-S2



8 MP IR Vari-focal Bullet WizMind Network Camera



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @30 fps.

> Max. IR distance: 120 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, power output supports max. 256 G Micro SD card.

> 24 VAC/12 VDC/PoE power supply.

> ePoE: IP67, IK10 protection, Heater.

> SMD 3.0.

> Anti-corrosion model optional.





8MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW5842H-ZHE



IPC-HFW5842H-ZHE



8MP IR Bullet WizMind Network Camera



> 8MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 8MP (3840×2160) @25fps/30fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detection, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Three streams for two-channel HD video

> IP67, IK10 protection grade

> 12V DC power output, max. current 165mA , easy for installation





8 MP IR Vari-focal Bullet WizMind Network Camera





DAHUA IPC-HFW5842H-ZHE-S2



IPC-HFW5842H-ZHE-S2



8 MP IR Vari-focal Bullet WizMind Network Camera



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160) @30 fps.

> Max. IR distance: 60 m.

> ROI, SVC, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, power output; supports max. 256 G Micro SD card.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> 24 VAC/12 VDC/PoE power supply.

> ePoE: IP67, IK10 protection, Heater.

> SMD 3.0.

> Anti-corrosion model optional.





4MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW7442H-Z



IPC-HFW7442H-Z



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264/H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





4MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW7442H-Z4



IPC-HFW7442H-Z4



4MP IR Bullet WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





4MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW7442H-Z4FR



IPC-HFW7442H-Z4FR



4MP IR Bullet WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recogni tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





4MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW7442H-ZFR



IPC-HFW7442H-ZFR



4MP IR Bullet WizMind Network Camera



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face recogni tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation







8MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW7842H-Z



IPC-HFW7842H-Z



> 8MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 8MP (3840×2160) @25fps/30fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





2MP WDR IR Bullet Network Camera





DAHUA IPC-HFW8231E-Z5E

IPC-HFW8231E-Z5E







2MP WDR IR Bullet Network Camera

> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS> H.265&H.264 triple-stream encoding> 50/60fps@1080P(1920×1080)> WDR(140dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 7mm ~35mm zoom lens> Max. IR LEDs Length 100m> Micro SD memory,IP67,IK10,PoE+







8MP IR Bullet WizMind Network Camera





DAHUA IPC-HFW7842H-Z4



IPC-HFW7842H-Z4



8MP IR Bullet WizMind Network Camera



> 8MP, 1/1.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP(3840 × 2160) @25/30 fps

> H.264&H.265 coding, high compression ration

> WDR, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detection, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





2MP WDR IR Bullet Network Camera





DAHUA IPC-HFW8231E-ZE



IPC-HFW8231E-ZE







2MP Starlight IR Bullet Network Camera





DAHUA IPC-HFW8232E-ZE



IPC-HFW8232E-ZE







2MP IR AI Bullet Network Camera





DAHUA IPC-HFW8241E-Z



IPC-HFW8241E-Z







12MP IR Bullet Network Camera





DAHUA IPC-HFW81230E-ZE



IPC-HFW81230E-ZE







2MP IR AI Bullet Network Camera





DAHUA IPC-HFW8241E-Z5



IPC-HFW8241E-Z5







2MP Starlight Bullet Network Camera





DAHUA IPC-HFW8242E-Z20FD-IRA-LED



IPC-HFW8242E-Z20FD-IRA-LED







2MP Starlight Bullet Network Camera





DAHUA IPC-HFW8242E-Z20FR-IRA-LED



IPC-HFW8242E-Z20FR-IRA-LED







2MP Dual-Lens Stereo Vision AI Network Camera





DAHUA IPC-HFW8241X-3D



IPC-HFW8241X-3D



2MP Dual-Lens Stereo Vision AI Network Camera



> Two 1/2.8” 2Megapixel progressive scan STARVISTM CMOS> H.265&H.264 triple-stream encoding> 25fps/30fps@1080P(1920×1080) > WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.8mm fixed lens (3.6mm, 6mm optional)> 3/2 Alarm in/out, 1/1 audio in/out, build-in MIC> Max. IR LEDs Length 40m> Micro SD memory 256GB, IP67, PoE> Five Types Stereo Analysis: Support fall detection,strand detection,people approach, people NO. error detection, violence detection





3MP WDR IR Bullet Network Camera





DAHUA IPC-HFW8331E-Z5E



IPC-HFW8331E-Z5E







2MP Starlight Bullet Network Camera





DAHUA IPC-HFW8242E-Z4FR-IRA-LED



IPC-HFW8242E-Z4FR-IRA-LED







2MP Starlight Bullet Network Camera





DAHUA IPC-HFW8242E-Z4FD-IRA-LED



IPC-HFW8242E-Z4FD-IRA-LED







6MP IR Bullet Network Camera





DAHUA IPC-HFW8630E-ZE



IPC-HFW8630E-ZE







4MP IR Bullet WizMind Network Camera (Special model for Mongolian market )





DAHUA IPC-HFW9442H-ZFR-MN



IPC-HFW9442H-ZFR-MN



4MP IR Bullet WizMind Network Camera (Special model for Mongolian market )



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688×1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





3MP WDR IR Bullet Network Camera





DAHUA IPC-HFW8331E-ZE



IPC-HFW8331E-ZE







4MP IR Bullet WizMind Network Camera (Special model for Mongolian market )





DAHUA IPC-HFW9442H-Z-MN



IPC-HFW9442H-Z-MN



4MP IR Bullet WizMind Network Camera (Special model for Mongolian market )



> 4MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Max outputs 4MP (2688 × 1520) @50 fps/60 fps

> H.264&H.265 coding, high compression ration

> Wide dynamic, day/ night, 3D NR, AWB, HLC, BLC

> ROI, SVC, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> With deep learning algorithm, it supports people counting, face detec tion, perimeter protection etc

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G SD card

> 24V AC/12V DC/PoE power supply (the power ports are different depending on the power supply)

> Five streams for three-channel HD video

> IP67, IK10 protection grade

> Anti-corrosion coating(optional)

> 12V DC power output, max. current 165mA , easy for installation





2MP WDR Pinhole Network Camera





DAHUA IPC-HUM4231



IPC-HUM4231







2MP Fixed-focal Pinhole Network Camera





DAHUA IPC-HUM4231-S2



IPC-HUM4231-S2



2MP Fixed-focal Pinhole Network Camera



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> RoI, SMART H.264+/H.265+, flexible coding, applicable to various band width and storage environments

> Rotation mode, WDR 120dB, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Tripwire and intrusion

> Abnormality detection: Motion detection, video tampering, scene chang ing, audio detection, network disconnection, IP conflict, illegal access, voltage detection

> Audio: 1 in, 1 out

> 12V DC power supply





2MP IR Network Camera





DAHUA IPC-K22A



IPC-K22A



> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Max. IR distance: 10 m

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Alarm: 1 in, 1 out; 256 G SD card, built-in Mic and speaker

> Supports 256 G Micro SD card

> 12V DC/PoE power supply, easy for installation

> Supports PIR





2MP IR Network Camera





DAHUA IPC-K22



IPC-K22



> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Max. IR distance: 10 m

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Alarm: 1 in, 1 out; 256 G SD card, built-in Mic and speaker

> Supports 256 G Micro SD card

> 12V DC power supply, easy for installation

> Supports PIR

> Supports Wi-Fi





4x2MP Panoramic Dome Network Camera





DAHUA IPC-PDB4830-B360



IPC-PDB4830-B360







4MP IR Network Camera





DAHUA IPC-K42



IPC-K42



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2560 × 1440) @25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Max. IR distance: 10 m

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Alarm: 1 in, 1 out; 256 G SD card, built-in Mic and speaker

> Supports 256 G Micro SD card

> 12V DC power supply, easy for installation

> Supports PIR

> Supports Wi-Fi





4MP IR Network Camera





DAHUA IPC-K42A



IPC-K42A



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition > Outputs max. 4MP (2560 × 1440) @25/30 fps> H.265 codec, high compression rate, ultra-low bit rate> Max. IR distance: 10 m> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, > H.264/H.265, flexible coding, applicable to various bandwidth and > Alarm: 1 in, 1 out; 256 G SD card, built-in Mic and speaker > Supports 256 G Micro SD card> 12V DC/PoE power supply, easy for installation > Supports PIR





4x2MP Multi-Sensor Panoramic IR Dome Network Camera





DAHUA IPC-PDBW8802-A180



IPC-PDBW8802-A180







4x2MP WizMind Multi-Sensor Panoramic Dome Network Camera





DAHUA IPC-PDBW8840-A180



IPC-PDBW8840-A180



4x2MP WizMind Multi-Sensor Panoramic Dome Network Camera

> Four 2MP 1/2.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (4096 × 1800) @30 fps

> Built-in IR LED, max. IR distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Intelligent functions: Crowd distribution map, Vehicle Density

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; 485; BNC; supports max. 256 G SD card

> 12V DC/24V AC/PoE power supply; easy for installation

> Supports object tracking

> IP67,IK10 protection









4 ¡Á 5MP WizMind Multi-Sensor No-Splicing Panoramic Dome Network Camera





DAHUA IPC-PDBW82041-B360



IPC-PDBW82041-B360



> 4-channel stream output, and each channel can output max. 5MP > ROI, SMART H.264+/H.265+, flexible coding, applicable to various > Support 4-channel 120dB WDR > The intelligent functions of 4 channels can be enabled at the same time> Intelligent detection: Tripwire, intrusion, fast moving (the three > FlexStream: The 4 channels of images can be viewed in a defined > Web5.0 interface design, which is friendly to users, and easy for operation> Built-in efficient IR LED illuminator, and the max. illumination distance is > Alarm: 3 in, 2 out; audio: 1 in, 1 out; 485; supports max. 256 G Micro SD > 12V DC/POE power supply; 12V power output, and max. current 165mA;

> IP67, IK10 protection









4x8MP Multi-Sensor Panoramic Bullet Network Camera





DAHUA IPC-PF83230-A180



IPC-PF83230-A180







4¡Á2MP WizMind Multi-Sensor Panoramic Network IR Bullet Camera





DAHUA IPC-PFW8840-A180



IPC-PFW8840-A180



4×2MP WizMind Multi-Sensor Panoramic Network IR Bullet Camera

> Four 2MP 1/2.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (4096 × 1800) @30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max. IR distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> DWDR, 3D NR, HLC, BLC, digital watermarking

> Intelligent functions: Crowd distribution map, Vehicle Density situation

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; 485; BNC; supports max. 256 G SD card

> 12V DC/24V AC/PoE power supply; easy for installation

> Supports object tracking

> IP67, IK10 protection









4x8MP WizMind Multi-Sensor Panoramic Bullet Network Camera





DAHUA IPC-PFW83242-A180



IPC-PFW83242-A180



4x8MP WizMind Multi-Sensor Panoramic Bullet Network Camera

> 4 × 8MP, 1/1.8″ CMOS image sensor, low illuminance, high image definition

> Outputs max. 32MP (8192 × 3840) @25/30 fps; with intelligent functions enabled, it can output 32MP (8192 × 3840) @25 fps

> Built-in IR LED, max. IR distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Intelligent detection: Intrusion, tripwire

> Intelligent functions: Crowd distribution map, Vehicle situation

> Supports object tracking and image correction

> Support video clip, the image can be clipped as needed

> Supports max. 256 G Micro SD card

> 12V DC power supply

> IP67, IK10 protection









8MP IR Dome WizMind Network Camera





DAHUA IPC-SBDMS7R8Z-G2



IPC-SBDMS7R8Z-G2



8MP IR Dome WizMind Network Camera



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 40 m.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC, supports max. 256 G Micro SD card.

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12V DC power output, max. current 165mA , easy for installation

> Anti-corrosion coating(optional)





8MP IR Bullet WizMind Network Camera





DAHUA IPC-SBBLS7R8Z-G2



IPC-SBBLS7R8Z-G2



> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 8 MP (3840 × 2160)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Built-in IR LED, and the max. illumination distance is 60 m.

> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter protection,etc.

> Supports P-Iris, the camera can control the iris more precisely for better image effect.

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict and illegal access.

> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card.

> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).

> IP67, IK10 protection grade.

> 12 VDC power output, max. current 165 mA , easy for installation

> Anti-corrosion coating(optional).





4MP IR Turret Network Camera





DAHUA IPC-T1B40



IPC-T1B40







4MP IR Turret Network Camera





DAHUA IPC-T2B40-ZS



IPC-T2B40-ZS







2MP IR Turret Network Camera





DAHUA IPC-T2B20-L-ZS



IPC-T2B20-L-ZS







2MP IR Turret Network Camera





DAHUA IPC-T2B20-ZS



IPC-T2B20-ZS







4/8/16 Channel Smart 1U 4K & H.265 Lite Network Video Recorder





DAHUA NVR4104/4108/4116-4KS2



NVR4104/4108/4116-4KS2



4/8/16 Channel Smart 1U 4K & H.265 Lite Network Video Recorder



> 4/8/16-channel IP video access

> Smart H.265+/Smart H.264+/H.265/H.264; H.265 auto switch

> Max 80 Mbps incoming bandwidth

> Up to 8MP resolution for preview and playback

> 8-channel decoding@1080p (30 fps)

> AI by Camera: Perimeter protection; SMD Plus; people counting; heat map





4 Channel 1U 2HDDs 4PoE 4K & H.265 Lite Network Video Recorder





DAHUA NVR4204-P-4KS2



NVR4204-P-4KS2



4 Channel 1U 2HDDs 4PoE 4K & H.265 Lite Network Video Recorder



> 4-channel IP video access

> Smart H.265+/Smart H.264+/H.265/H.264; H.265 auto switch

> Max 200 Mbps incoming bandwidth

> Up to 8MP resolution for preview and playback

> 8-channel decoding@1080p (30 fps)

> AI by Camera: Perimeter protection; SMD Plus; people counting; heat map

> Support IPC UPnP, 4 PoE ports





4x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera





DAHUA PSD8802-A180



PSD8802-A180



4x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera



> Panoramic: Four 1/1.8” 2Megapixel progressive scan CMOS> PTZ: One 1/1.8” 2Megapixel progressive scan CMOS> H.265/H.264 triple-stream encoding > 25fps@4096×1800+50/60fps@1080P> Support 180-degree panoramic view> Day/Night(ICR), 3DNR, AWB, AGC, BLC> Smart tracking> Intelligent Function> Micro SD memory, IP67, IK10





2MP Multi-Sensor Network Camera+PTZ Camera





DAHUA PSDW5231S-B120



PSDW5231S-B120



> Panoramic: 1/2.7” 2Megapixel progressive scan CMOS

> PTZ: 1/2.7” 2Megapixel progressive scan CMOS

> H.265/H.264 dual-stream encoding

> 25fps@1920×1080

> Day/Night(ICR), 3DNR, AWB, AGC, BLC

> Max IR LEDs Length 15m

> Micro SD card slot, up to 256GB

> PoE





8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera





DAHUA PSD81602-A360



PSD81602-A360



8x2MP Multi-Sensor Panoramic Network Camera+PTZ Camera



> Panoramic: Eight 1/1.8” 2Megapixel progressive scan CMOS> PTZ: One 1/1.8” 2Megapixel progressive scan CMOS> H.265/H.264 triple-stream encoding > 2x25fps@4096×1800+50/60fps@1080P> Support 360-degree panoramic view> Day/Night(ICR), 3DNR, AWB, AGC, BLC> Smart tracking> Intelligent Function> Micro SD memory, IP67, IK10

















4MP IR Vari-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3441T-ZAS



IPC-HFW3441T-ZAS



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520)@30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 60 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio abnormality detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: In, out; Audio: In, out; Supports max. 256 G Micro SD card

> 12V DC/POE power supply

> IP67, IK10(optional) protection

> SMD Plus



2MP IR Fixed focal Eyeball WizSense Network Camera





DAHUA IPC-HDW3241TM-AS



IPC-HDW3241TM-AS



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080)@30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 50 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Supports max. 256 G Micro SD card, built-in Mic

> 12V DC/POE power supply

> IP67 protection

> SMD Plus



4MP IR Fixed focal Eyeball WizSense Network Camera





DAHUA IPC-HDW3441TM-AS



IPC-HDW3441TM-AS



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520) @30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 50 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Supports max. 256 G Micro SD card, built-in Mic

> 12V DC/POE power supply

> IP67 protection

> SMD Plus



2MP IR Vari-focal Bullet WizSense Network Camera





DAHUA IPC-HFW2241T-ZS



IPC-HFW2241T-ZS



> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2 MP (1920 × 1080)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 (optional) protection.

> SMD Plus.



DAHUA IPC-HFW3441M-AS-I2 4MP IR Fixed focal Bullet WizSense Network Camera





DAHUA IPC-HFW3441E-AS-S2



IPC-HFW3441E-AS-S2



> Outputs max. 4 MP (2688 × 1520) @25/30 fps. > H.265 codec, high compression rate, ultra-low bit rate.> Built-in IR LED, max. IR distance: 50 m. > ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. > Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human). > Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.> Alarm: 1 in, 1 out (Only – AS supports); audio: 1 in, 1 out (Only – AS supports); max. 256 G Micro SD card. built-in Mic. > 12 VDC/PoE power supply facilitates installation.> IP67 protection.> SMD 4.0, AI SSA.



DAHUA IPC-HFW3241M-AS-I2 2MP IR Fixed focal Bullet WizSense Network Camera





DAHUA IPC-HFW3241E-AS-S2



IPC-HFW3241E-AS-S2



> Outputs max. 2 MP (1920 × 1080) @25/30 fps > H.265 codec, high compression rate, ultra-low bit rate> Built-in IR LED, max. IR distance: 50 m > ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicableto various monitoring scenes > Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human) > Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection> Alarm: 1 in, 1 out (Only – AS supports); audio: 1 in, 1 out (Only – AS supports); max. 256 G Micro SD card. built-in Mic > 12 VDC/PoE power supply facilitates installation> IP67 protection> SMD 4.0, AI SSA



DAHUA IPC-HFW3441M-AS-SFC-I2 4MP Anti-oil IR Fixed focal Bullet WizSense Network Camera





DAHUA IPC-HFW3449T1-ZAS-PV



IPC-HFW3449T1-ZAS-PV



> 4-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 4 MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m.

> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk.

> 12 VDC/PoE power supply.

> IP67 protection.

> Sound and light alarm (red and blue lights).

> SMD 4.0.

> One-click arming/disarming through alarm input.



2MP Smart Dual Light Fixed-focal Eyeball WizSense Network Camera





DAHUA IPC-HDW2249TM-S-IL



IPC-HDW2249TM-S-IL



> Outputs max. 2 MP (1920 × 1080)@25/30 fps.> H.265 codec, high compression rate, ultra-low bit rate.> Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).> Supports max. 256 G Micro SD card; built in MIC.> 12 VDC/PoE power supply, easy for installation.> IP67 protection.> SMD Plus.



2MP IR Vari-focal Bullet WizSense Network Camera





DAHUA IPC-HFW2241T-ZS



IPC-HFW2241T-ZS



> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.

> Outputs max. 2 MP (1920 × 1080)@25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, and the max. illumination distance is 60 m.

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – ZAS supports); audio: 1 in, 1 out (Only – ZAS supports); supports max. 256 G Micro SD card; built in MIC.

> 12 VDC/PoE power supply, easy for installation.

> IP67, IK10 (optional) protection.

> SMD Plus.



5 MP IR Fixed-focal Bullet WizSense Network Camera





DAHUA IPC-HFW3541E-S-S2



IPC-HFW3541E-S-S2



> 5-MP 1/2.7″ CMOS image sensor, excellent low luminance performance and high definition of images.

> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps.

> H.265 codec, high compression rate, ultra-low bit rate.

> Built-in IR LED, max. IR distance: 50 m.

> ROI, SMART H.264 +/H.265+, AI H.264/H.265. flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).

> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.

> Alarm: 1 in, 1 out (Only – AS supports); audio: 1 in, 1 out (Only – AS supports); max. 256 G Micro SD card. built-in Mic.

> 12 VDC/PoE power supply, easy for installation.

> IP67 protection.

> SMD 4.0, AI SSA.



4MP IR Fixed focal Bullet WizSense Network Camera





DAHUA IPC-HFW3441M-AS-I2



IPC-HFW3441M-AS-I2



> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition

> Outputs max. 4MP (2688 × 1520)@30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 80 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; Audio: In, out; supports max. 256 G Micro SD card

> 12V DC/PoE power supply, 12V power output, max. current 165mA

> IP67 protection

> SMD Plus



2MP IR Fixed focal Bullet WizSense Network Camera





DAHUA IPC-HFW3241M-AS-I2



IPC-HFW3241M-AS-I2



> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080)@30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 80 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; Audio: In, out; supports max. 256 G Micro SD card

> 12V DC/PoE power supply, 12V power output, max. current 165mA

> IP67 protection

> SMD Plus



3MP IR Mini Eyeball Network Camera





DAHUA IPC-MDW4330-M12



IPC-MDW4330-M12



3MP IR Mini Eyeball Network Camera



> 1/3” 3Megapixel progressive scan CMOS> H.265&H.264 triple-stream encoding> 25fps@3M(2048×1536)> DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC,> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS> 2.1mm fixed lens (2.8mm, 3.6mm optional)> Max. IR LEDs Length 20m> Micro SD memory> EN50155, E-MARK(ECE-Regulation No.10)







2MP 31x Starlight IR WizMind PTZ Network Camera





DAHUA PTZ4M231-HNR-XA-GHW



PTZ4M231-HNR-XA-GHW



2MP 31x Starlight IR WizMind PTZ Network Camera



> 1/1.8″ 2Megapixel STARVIS™ CMOS

> 31× optical zoom

> Starlight+ technology

> Max. 25/30 fps@1080p

> IR distance up to 100 m

> Auto-tracking

> Perimeter protection

> Face detection

> Construction monitoring

> SMD Plus

> GPS positioning, displaying accurate longitude and latitude

> Dual 4G (SIM 1/SIM 2)

> Dual SD card expansion (TF1/TF2)

> Bluetooth, Wi-Fi (2.4G/5G), AP (2.4G/5G)





4MP 25x Starlight IR WizMind Explosion-proof Network Camera





DAHUA ECA7A1425-HNR-XA-F



ECA7A1425-HNR-XA-F



4MP 25x Starlight IR WizMind Explosion-proof Network Camera

> 1/1.8″ 4Megapixel CMOS> 25x optical zoom (5.4 mm–135 mm)> Starlight technology> Max. 25/30fps@4MP> IR distance up to 100 m> Perimeter protection> Face detection> Smart Capture> SMD PLUS > Fiber port







4MP 4x Explosion-proof IR WizMind Network Camera





DAHUA ECA3A1404-HNR-XB



ECA3A1404-HNR-XB



> 4x optical zoom and 16x digital zoom> Adopts anti-corrosion stainless steel 304, and 316L is customizable> Starlight technology> Max. 25/30 fps@4M> IR distance up to 40 m> SMD Plus> Supports perimeter protection, smart capture, and face detection



4MP 4x Explosion-proof IR WizMind Network Camera





DAHUA ECA3A1404-HNR-XB-F



ECA3A1404-HNR-XB-F



> 4x optical zoom and 16x digital zoom> Adopts anti-corrosion stainless steel 304, and 316L is customizable> Starlight technology> Max. 25/30 fps@4M> IR distance up to 40 m> SMD Plus> Supports perimeter protection, smart capture, and face detection> Optical Fiber



2MP 30x Explosion-proof IR Network Camera





DAHUA EPC230U



EPC230U



2MP 30x Explosion-proof IR Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS> Powerful 30x optical zoom> 304 stainless steel housing> Starlight technology> H.265 Encoding> Max. 50/60fps@1080P> Support IVS> IR distance up to 100m> ATEX and IECEx Certifacation> IP68









2MP 30x Anti-corrosion PTZ Network Camera





DAHUA SD60230U-HNI-SL



SD60230U-HNI-SL



2MP 30x Anti-corrosion PTZ Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS> Powerful 30x optical zoom> Starlight technology> H.265 Encoding> Max. 50/60fps@1080P> Auto-tracking and IVS> Support PoE+> IP68, IK10, NEMA 4X> Material: 316L Stainless steel



Flame Detection Network Camera





DAHUA HY-FT121LD



HY-FT121LD



> Uncooled VOx thermal sensor technology

> Flame detection with adjustable and high sensitivity

> Support GB/T 28182 and ONVIF, convenient for integration

> WDR, 3D NR, applicable to various monitoring scenes

> Support tracking flame position

> Flame detection with adjustable sensitivity

> Strobe light & audio and remote intercom

> Built-in 1/1 alarm in/out, flexible alarm linkage

> IP66, PoE

> Built-in alarm voices, and user can import custom voices

> 2MP 1/2.7″ CMOS image sensor, low luminance, and high definition image

> 12V DC/PoE power supply

> Built-in IR light; the max. IR LEDs Length is 15 m (49.21 ft)



5MP IR AI-fire Smoke Sensing Network Camera





DAHUA HY-SAV849HA-E



HY-SAV849HA-E



> Remote check based on smoke sensing and video alarm linkage

> Intelligent monitoring: Flame detection

> With split-spectrum smoke chamber and intelligent algorithm,eliminate the false alarm effectively

> Ultra-low power consumption design allows 3-year operation ofsmoke sensing module with built-in battery

> Built-in high decibel buzzer, smoke alarm is over 80 dB at 3 meters

> Self-test and low battery warning

> Intelligent compensation algorithm relieves the impact of dustaccumulation and environment changing on smoke sensing module

> Insect-proof and dust-proof design for smoke sensing module

> Built-in alarm voices, and user can import custom voices

> 5MP 1/2.7″ CMOS image sensor, low luminance, and high definitionimage

> H.265 codec, high compression rate, ultra-low bit rate

> Flip mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable tovarious monitoring scenes

> 2/2 Alarm in/out, 1/1 audio in/out; supports max. 256 GB Micro SDcard; built-in Mic and speaker

> Flip mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable tovarious monitoring scenes

> 12V DC/PoE power supply

> Built-in IR light; the max. IR LEDs Length is 20 m (65.62 ft)



2MP 30x Anti-corrosion IR Network Camera





DAHUA SDZW2030U-SL

SDZW2030U-SL



2MP 30x Anti-corrosion IR Network Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS> Powerful 30x optical zoom> Starlight technology> H.265 Encoding> Max. 50/60fps@1080P> IVS> IP68> Material: 316L Stainless steel







Flame Detection Network Camera





DAHUA HY-FT431LDP



HY-FT431LDP



Flame Detection Network Camera



> Industry leading uncooled VOx focal plane detector with high sensitivity> Supports fire detection alarm, cold and hot spot alarm, and industrial temperature detection alarm functions> Supports sound and light alarm linkage, and supports binocular fusion> Visible light adopts a 4MP 1/2.7 inch CMOS image sensor, which has good low illumination effect and high image clarity> Support multi-level user management, humanized monitoring, confidentiality, and permission management> Supports H.265 encoding with high compression ratio, achieving ultra-low bitstream transmission> Supports 1-way alarm input and 1-way alarm output functions, convenient linkage > Built in MIC and high volume speakers, high decibel alarm sound 70dB ¡Ý 1m (A-weighted) > Built in high-efficiency infrared fill light, with a maximum infrared monitoring distance of 15 meters> Support DC12V/POE power supply mode for easy engineering installation> Supports IP66 protection level



5MP IR AI-Fire Smoke Sensing Network Camera with Temperature and Humidity Detection





DAHUA HY-SAV849HA-ET



HY-SAV849HA-ET



> Remote check based on smoke sensing and video alarm linkage

> Intelligent monitoring: Flame detection

> High precision temperature and humidity sensors are used to moni- tor the temperature and humidity data in the equipment environment

> With split-spectrum smoke chamber and intelligent algorithm, elimi- nate the false alarm effectively

> Ultra-low power consumption design enables the smoke sensing mod- ule to operate for 3 years with only battery

> Built-in high decibel buzzer, smoke alarm is over 85 dB at 3 meters

> Self-test and low battery warning

> Intelligent compensation algorithm relieves the impact of dust accu- mulation and environment changing on smoke sensing module

> Insect-proof and dust-proof design for smoke sensing module

> Built-in alarm voice, and user can import custom voices

> 5MP 1/2.7″ CMOS image sensor, low luminance, and high definition image

> H.265 codec, high compression rate, ultra-low bit rate

> Flip mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> 2/2 Alarm in/out, 1/1 audio in/out; supports max. 256 GB Micro SD card; built-in Mic and speaker

> 12V DC/PoE power supply

> Built-in IR light; the max. IR LEDs Length is 20 m (65.62 ft)





Enhanced Classification and Categorization

In addition to introducing new technology, Dahua has also streamlined its camera offerings with enhanced classification and categorization. The Night Color Technology, previously available across multiple camera models, has been reorganized into three distinct categories:

• Basic Night Color
• Enhanced Night Color
• Night Color+

This reclassification simplifies the selection process for security dealers and integrators, allowing them to choose the right camera for each specific application with confidence.

Expanded Product Lineup

Alongside the advancements in Night Color Technology, Dahua has expanded its product lineup to include new offerings such as the Enhanced Night Color 180° panoramic camera series. These cameras feature dual 4MP sensors and a wide field of view, providing comprehensive coverage and exceptional image quality.

Furthermore, Dahua’s network cameras come equipped with Smart Object Detection, a component of the company’s Analytics+ technology. This advanced feature analyzes scenes to trigger alarms based on predefined criteria, enhancing situational awareness and proactive threat detection.

Seamless Integration and Deployment

Integrating Dahua’s network cameras into existing security systems is seamless, thanks to their compatibility with a wide range of third-party devices and software platforms. Whether deploying standalone cameras or comprehensive surveillance solutions, users can expect effortless integration and reliable performance.

Moreover, Dahua’s commitment to user-centered design is evident in the cameras’ intuitive interfaces and simplified setup processes. With features like Easy Installation, Easy Connection, Easy Configuration, Easy Usage, and Easy Maintenance, Dahua ensures a hassle-free experience for security professionals and end-users alike.

Partnership with CCTV-MALL

Dahua’s network cameras are available through its core sales channel, CCTV-MALL, a leading provider of video surveillance solutions. With a strong emphasis on customer service and competitive pricing, CCTV-MALL has established itself as a trusted partner for security integrators and end-users worldwide.

By maintaining a close relationship with Dahua, CCTV-MALL offers access to the latest products and technologies, backed by comprehensive support and expertise. Whether sourcing individual cameras or complete surveillance systems, customers can rely on CCTV-MALL for superior solutions tailored to their specific needs.

Conclusion

With the unveiling of its next-gen network camera technology, Dahua reaffirms its commitment to innovation, quality, and customer satisfaction. These advanced cameras represent the pinnacle of video surveillance technology, empowering security professionals to achieve their objectives with confidence and efficiency.

As the global demand for reliable security solutions continues to grow, Dahua remains at the forefront of the industry, driving innovation and setting new standards for excellence. With its extensive product portfolio, strategic partnerships, and unwavering dedication to customer success, Dahua is poised to shape the future of video surveillance for years to come.

Discover the latest advancements in video surveillance technology with Dahua’s next-gen network cameras. Featuring advanced features, enhanced performance, and seamless integration, these innovative cameras offer superior security solutions for a wide range of applications. Explore Dahua’s partnership with CCTV-MALL, a leading provider of video surveillance solutions, and experience the future of surveillance technology today.
